Z5032C/1radial borehole vertical metal column drill machine hand drilling and milling taladro de press perforadora driller

Z5032C/1radial borehole vertical metal column drill machine hand drilling and milling taladro de press perforadora driller

Price:RUB 84,161.22 - RUB 122,416.32

Price in USD:Details

Quantity:

Offer

/Vertical drilling machine Z5032C/1 with step-changed cyclically spindle speed

Drilling Machine	Z5032C/1
Max. drilling capacity	32mm
Spindle taper	M. T. 3 or R8
Spindle travel	130mm
Step of speed	6
Range of spindle speed 50Hz	80-1250 r. p. m
60Hz	95-1500 r. p. m
Step of spindle auto-feeding	6
Range of spindle auto-feeding amount	0.06-0.30mm/r
Min. distance from spindle axis to column	290mm
Max. distance from spindle nose to worktable	700mm
Max. distance from spindle nose to stand table	1125mm
Max. travel of headstock	250mm
Swivel angle of headstock(horizontal)	360°
Max. travel of worktable bracket	600mm
Worktable size of avaliablity	730× 210mm
Swivel angle of table horizontally	360 degree
Table leaned	± 45°
Size of stand worktable of avaliability	417× 416mm
Motor power	0.75KW(1HP)
Voltage/Frequency	As customer' s requirement
speed of motor	1400 r. p. m
Cooling pump power	0.04KW
Net weight/Gross weight	437kg/487kg
Packing size	1850× 750× 1000mm
Loading amount	18pcs/20" container
