Rang of application | laptop ADAPTER | |||||||||||||||
Input specification | Input voltage | 100-240V ( worldwide use) | ||||||||||||||
Input frequency | 50-60Hz | |||||||||||||||
Input surge | 1.2-1.5A | |||||||||||||||
Output specification | Output voltage | 16.5V | ||||||||||||||
Output current | 3.65A | |||||||||||||||
Output power | 60W | |||||||||||||||
Protection function | Overload protection | Beyond the rated power10%-15%, automatic recovery | ||||||||||||||
Over-voltage protection | 10%-15%Out of rated voltage | |||||||||||||||
Short Circuit | No damage for short circuit,automatic recovery | |||||||||||||||
Environmental | Operating temperature | 30°C-55°C | ||||||||||||||
Storage temperature | (-20 °C-55°C) | |||||||||||||||
AC specification | 2PIN C8 | Device type | Desktop adapter | |||||||||||||
structure | weight | 190G | Ripple | <=100MV | ||||||||||||
color | White | Efficiency | 89% | |||||||||||||
Size | 75*75*29mm | Safety standards | CE FCC ROSH IEC MSDS | |||||||||||||
External dimension | l-tip | Service | OEM ODM OBM | |||||||||||||
Internal dimension | l-tip | Warranty | 1 year warranty |
