3w 4w 6w 9w 12w 15w 18w 24w round square 6 inch multi color recessed slim light
- Category: >>>
- Supplier: Jiaxing Bamboo Import And Export Co. Ltd.
Share on (1600136183136):
Product Overview
Description
Product Description
LED ceiling panel light, 3w-24w with different size and different warranty. 3-5 year warranty. 110-130lm/w.
Watt | 3w | 6w | 9w | 12w | 15w | 18w | 21w | 24w | |||||||||
Voltage | AC85-265V | ||||||||||||||||
Size(mm) | 85*12 | 120*12 | 145*12 | 170*12 | 195*12 | 225*12 | 240*12 | 300*12 | |||||||||
Cut-out(mm) | 70 | 105 | 125 | 150 | 175 | 205 | 220 | 280 | |||||||||
Lumen | 90-100LM/W 110-120LM/W | ||||||||||||||||
CCT | 2700-6500K / RGB | ||||||||||||||||
Materials | Aluminum + Ps | ||||||||||||||||
CRI | CRI80 | ||||||||||||||||
PF | 0.5 / 0.9 | ||||||||||||||||
IP | IP44 | ||||||||||||||||
Shape | Round / Square | ||||||||||||||||
Installation | Recessed | ||||||||||||||||
Warranty | 2-3 Year | ||||||||||||||||
LED panel downlight 3w- 24w, round and square type, recessed installation.
LED panel downlight , usually we provide three types CCT , at the same time, we also accept to do different specific CCT.
3000-3500K | Warm white |
4000-4500K | Nature white |
6000-6500K | Cool white |
Other | Customized |
According to different products and different order volume, there have four types for customer to choose shipping way.
Shipping type | Shipping time | Shipping cost | Remark |
By Express | 3-5 workdays | Highest | Time Urgent, small order/sample order |
By Air | 4-9 workdays | Medium | Time no very urgent, small wholesales |
By Train | 10-20 workdays | Lower | Asian and Europen Railway joint Transport |
By Sea | Depend on port distance | Lowest | Tme enough, bulk purchase |
Installation
1. Power off before installation
2. Drill proper hole into the ceiling according to product model
3. Connect AC wire
4. Embed the light into ceiling hole
5. Light up and test; installation finish
2. Drill proper hole into the ceiling according to product model
3. Connect AC wire
4. Embed the light into ceiling hole
5. Light up and test; installation finish
1: Please check the lamp carefully before installing.
2: Ensure the power is offer before wiring and installation.
3: To help ensure it's longevity, please do not use this lamp in corrosive conditions.
4: If there is any damage to the lamp cord, please cut off the power and stop using it immediately.
5: Please do not retrofit the lamp within the warranty period.
6: To ensure normal work of the lamp, please use the voltage indicated on the packing.
Warnings :
1: Please install the lamp according to instructions of this user guide.
2: To avoid any injuries from fallen lamp or electric shock, please do not retrofit this lamp at random.
Genneral troubleshooting :
If the lamp is installed properly, Please figure out whether the failure is caused by following situations. If all following
resolutions do not work, please stop using immediately and contact professionals or retailers for help.
1: If the lamp does not work, please cut off the power and then check whether the power cord of lamp is properly connected with mains supply.
2: If connected properly, please ask a professional to check the input voltage or circuit.
Routine maintenance ：
1: To ensure better lighting, please clean LED lights once a year.
2: Please make sure the power is off before your maintenance work.
3: To avoid any damage to the lamp, please do not use chemical solvent during routine maintenance.
4: If you need to replace any components or cords of the lamp, please choose those having the same specifications.
2: Ensure the power is offer before wiring and installation.
3: To help ensure it's longevity, please do not use this lamp in corrosive conditions.
4: If there is any damage to the lamp cord, please cut off the power and stop using it immediately.
5: Please do not retrofit the lamp within the warranty period.
6: To ensure normal work of the lamp, please use the voltage indicated on the packing.
Warnings :
1: Please install the lamp according to instructions of this user guide.
2: To avoid any injuries from fallen lamp or electric shock, please do not retrofit this lamp at random.
Genneral troubleshooting :
If the lamp is installed properly, Please figure out whether the failure is caused by following situations. If all following
resolutions do not work, please stop using immediately and contact professionals or retailers for help.
1: If the lamp does not work, please cut off the power and then check whether the power cord of lamp is properly connected with mains supply.
2: If connected properly, please ask a professional to check the input voltage or circuit.
Routine maintenance ：
1: To ensure better lighting, please clean LED lights once a year.
2: Please make sure the power is off before your maintenance work.
3: To avoid any damage to the lamp, please do not use chemical solvent during routine maintenance.
4: If you need to replace any components or cords of the lamp, please choose those having the same specifications.
Suitable for shop, supermarket, shopping mall, hospital, office, house, shopping mall, factory and other indoor places.
Application
More Recommend
Company profile
Bamboo Company is a manufacturer of LED lighting established in 2008. It has been focusing on the production and export of indoor and outdoor lamps for more than ten years.
The company has strong technical force, complete testing equipment, high quality products, reasonable prices and fashionable styles, and has been widely recognized and trusted by customers.
We welcome new and old customers from all walks of life to contact us for future business relations and common success!
We welcome new and old customers from all walks of life to contact us for future business relations and common success!
FAQ
Q1. Can I have a sample order for led light?
A: Yes, we welcome sample order to test and check quality. Mixed samples are acceptable.
Q2. What about the lead time?
A: Sample needs 3-5 days, Wthin Moq need 5-7 days, other quantity need to be discuss.
Q3. Do you have any MOQ limit for led light order?
A: Low MOQ, 1pc for sample checking is available
Q4. How do you ship the goods and how long does it take to arrive?
A: We usually ship by DHL, UPS, FedEx or TNT. It usually takes 3-5 days to arrive. Airline and sea shipping also optional.
Q5. How to proceed an order for led light?
A: Firstly let us know your requirements or application.
Secondly We quote according to your requirements or our suggestions.
Thirdly customer confirms the samples and places deposit for formal order.
Fourthly We arrange the production.
Q6. Is it OK to print my logo on led light product?
A: Yes. Please inform us formally before our production and confirm the design firstly based on our sample.
Q7: Do you offer guarantee for the products?
A: Yes, we offer 2-3-5 years warranty to our products.
Q8: How to deal with the faulty?
A: Firstly, Our products are produced in strict quality control system and the defective rate will be less
than 0.2%.
Secondly, during the guarantee period, we will send new lights with new order for small quantity. For defective batch products, we will repair them and resend them to you or we can discuss the solution including re-call according to real situation.
A: Yes, we welcome sample order to test and check quality. Mixed samples are acceptable.
Q2. What about the lead time?
A: Sample needs 3-5 days, Wthin Moq need 5-7 days, other quantity need to be discuss.
Q3. Do you have any MOQ limit for led light order?
A: Low MOQ, 1pc for sample checking is available
Q4. How do you ship the goods and how long does it take to arrive?
A: We usually ship by DHL, UPS, FedEx or TNT. It usually takes 3-5 days to arrive. Airline and sea shipping also optional.
Q5. How to proceed an order for led light?
A: Firstly let us know your requirements or application.
Secondly We quote according to your requirements or our suggestions.
Thirdly customer confirms the samples and places deposit for formal order.
Fourthly We arrange the production.
Q6. Is it OK to print my logo on led light product?
A: Yes. Please inform us formally before our production and confirm the design firstly based on our sample.
Q7: Do you offer guarantee for the products?
A: Yes, we offer 2-3-5 years warranty to our products.
Q8: How to deal with the faulty?
A: Firstly, Our products are produced in strict quality control system and the defective rate will be less
than 0.2%.
Secondly, during the guarantee period, we will send new lights with new order for small quantity. For defective batch products, we will repair them and resend them to you or we can discuss the solution including re-call according to real situation.
