Digital Display Electronic Tensile Strength Testing Machine Double Column Spring Material Universal Tensile Testing Machine Mainly applicable to the test of metal and non-metal materials, such as rubber, plastic, wire and cable, optical fiber and cable, safety belt, safety belt, leather belt composite material, plastic profile, waterproof coil, steel pipe, copper material, profile, spring steel, bearing steel, stainless steel (and other high hardness steel), casting, steel plate, steel belt, non-ferrous metal wire stretching, compression, bending, shearing Cutting, stripping, tearing, two point extension (need to be equipped with extensometer) and other tests.


Specification


est item
Power and selective elongation
display
Visualizzazione per Pc
Unit of force
Kg, N, Lb, and g
Extension unit
mm, cm, in %
Capacity selection
1.2.5.10, 20, 50, 100, 200, 500kg, 1000kg, 2000kg, 5000kg, 10000kg
Load element accuracy
Less than 0.5%
Force resolution
1/100000
Test maximum stroke
The maximum is 1200mm eycludina the fixture
Effective test space
Diameter range 400mm
Test speed
0.1-1 000mm/min can be adjusted arbitrarily
Stop mode
Upper and lower limit safety setting, emergency stop key, program force and elongation setting and test piece breakpoint sensing
Equip with
Standard preparation fixture set, use help book and product warranty card each
power
De dc motor
Standard arrangement
Computer connection equipment (1 signal cable, 1 decryption lock, 1 program CD)
