Машина для резки гофрированного ножа с ЧПУ из пенопласта, кожи, ПВХ
- Category: Cloth Cutting Machines >>>
- Supplier: Jiangsu,Honghua,Special,Equipment,Co.,Ltd.
Share on:
Product Overview
Description
Products Description
Flexible material vibrating knife cutting machine, specially tailored for the garment industry, plush fabrics, sofas, leather, non-woven fabrics, composite materials, flannel, etc. It can accurately cut a variety of clothing fabrics with any graphics, and can be equipped with a feeding device , Realize continuous automatic cutting of coil material. The marking and cutting process of the garment piece can be completed at one time. Vacuum adsorption and crawler transfer worktables make it convenient to receive and feed materials. Cutting fabrics includes various materials such as plush fabrics, non-woven fabrics, cotton and linen, and chemical fibers. It can be used with a scanner to quickly produce samples. The vibrating knife cutting machine has no smoke when working, saving materials, cutting edges without focal edges, cutting will not shed fluff, and working environmentally friendly and pollution-free.
Vibrating knife garment cutting machine, vibrating knife garment cutting machine adopts blade cutting, intelligent numerical control, with automatic feeding and automatic cutting functions, proofing, suitable for single-layer or small multi-layer high-definition clothing, and can be intelligently installed and automatically aligned The striping system realizes automatic cutting of grids. The software has super typesetting software, which can realize automatic typesetting of materials. Compared with manual cutting and typesetting, it can save more than 10% of materials. Intelligent error compensation system cutting error ±0.01mm/s.
Configuration
model: | Vibrating knife cutting machine |
Repeatability: | 0.1mm |
Working speed: | 0-1200mm/s |
Rated voltage: | 380V50HZ |
Motor | Servo motor |
Tool: | Vibrating knife/round knife/drag knife/stroke tool/half cutter/ milling cutter/slotting cutter/rotary cutter/ hob/ creasing cutter/ultrasonic cutter |
transfer method: | Rack drive (higher precision and rigidity than belt drive); |
Drive mode: | Fully digital servo drive (fast response, high speed, strong anti-interference ability, sensitive braking; rack and servo start fast and not flexible) |
Vibration motor: | High frequency vibration motor (strong force and fast speed) |
operating system: | Fully intelligent DSP offline system (no need to program to import graphics can be cut directly, simple and easy to operate); |
Longmen structure: | Aluminum alloy integrated gantry structure (light load and fast running speed); |
Cutting platform: | (Vacuum adsorption, felt) The whole sheet, the whole sheet can be used for a long time, the platform is not deformed, it is reflected on the product, and there will be no impervious phenomenon in some places; |
Body structure: | Integral welding type (resistance to vibration, no deformation, processing accuracy of the product); |
Fan: | Vacuum adsorption fan |
Tool equipment: equipped with vibrating knife, drag knife, stroke tool and optional half cutter, milling cutter, slotting cutter, rotary cutter, hob, creasing cutter, ultrasonic cutter and other tools, which can realize writing line and dotted line Cutting, semi-cutting, full-cutting, blank milling, plate grooving, large and small pressure wheel indentation, hard material cutting, etc., to solve the cutting process of different materials.
Multi-layer/single-layer knife cutting machine functions:
1. Two interchangeable tool heads and integral head frame for easy tool replacement.
2. Four-axis high-speed motion controller, modular installation, convenient for maintenance.
3. The cutting depth can be adjusted arbitrarily.
4. Simple parameter setting, different materials can be processed as long as the thickness and speed are set.
5. It can easily expand the functions of the upgraded equipment and load new modules.
6. Vibrating knife cutting function: It can cut different materials (corrugated paper, cardboard, rubber gray board color, composite paper, gasket, leather and cloth, etc.).
7. Folding line function: It can press perfect folding line on corrugated paper, cardboard, rubber sheet and other materials.
8. Dotted line cutting function: It is used to fold corrugated paper and cardboard after half-cutting, and cut dotted line.
9. Positioning function: use laser light to accurately position.
10. Drawing function: can draw various high-precision patterns.
1. Two interchangeable tool heads and integral head frame for easy tool replacement.
2. Four-axis high-speed motion controller, modular installation, convenient for maintenance.
3. The cutting depth can be adjusted arbitrarily.
4. Simple parameter setting, different materials can be processed as long as the thickness and speed are set.
5. It can easily expand the functions of the upgraded equipment and load new modules.
6. Vibrating knife cutting function: It can cut different materials (corrugated paper, cardboard, rubber gray board color, composite paper, gasket, leather and cloth, etc.).
7. Folding line function: It can press perfect folding line on corrugated paper, cardboard, rubber sheet and other materials.
8. Dotted line cutting function: It is used to fold corrugated paper and cardboard after half-cutting, and cut dotted line.
9. Positioning function: use laser light to accurately position.
10. Drawing function: can draw various high-precision patterns.
Features
1. Adopting vibrating knife cutting technology, no need to make knife molds, save the cost and time of knife mold manufacturing, management, storage, etc. in the production and development process, completely bid farewell to the traditional manual knife mold cutting process, and completely break through the enterprise's dependence on skilled workers The bottleneck is the first to enter the era of digital toolless machining.
2. Multifunctional cutting head design, highly integrated multiple sets of processing tools, interactive cutting, punching, and marking can be performed in one work unit to achieve one-stop operation.
3. It can complete the pattern cutting with high difficulty, complicated style, and the model cannot be realized by the knife mold, which greatly expands the shoe pattern.
4. The designer's design space creates new styles that cannot be imitated by hand-cutting, making your model more attractive, and making the design truly reach the realm of "not afraid of not being able to do it, but afraid of not thinking about it".
5. The powerful nesting and counting system can achieve automatic nesting and accurate counting, so as to accurately calculate the cost, accurately control the material distribution, and truly realize the digital zero inventory strategy.
5. The leather contour can be captured by projector projection or camera shooting, which can effectively identify leather defects. According to the natural texture of the leather, the cutting direction can be adjusted arbitrarily to increase the yield and reduce the loss, thereby improving the effective utilization of the material. Through the computer to accurately simulate each operation process, the program operation can be realized, and the traditional cutting of the material due to the emotions and skills of the workers Interference from personal factors such as fatigue, fatigue, etc., to avoid hidden waste, thereby increasing material usage.
7. It is possible to modify the template in time, save the time of developing the board, quickly release the board, quickly change the board, and adapt to the rapidly changing market demand.
8. The same board adjustment can be 2-3 days ahead of competitors, helping you quickly seize market opportunities.
2. Multifunctional cutting head design, highly integrated multiple sets of processing tools, interactive cutting, punching, and marking can be performed in one work unit to achieve one-stop operation.
3. It can complete the pattern cutting with high difficulty, complicated style, and the model cannot be realized by the knife mold, which greatly expands the shoe pattern.
4. The designer's design space creates new styles that cannot be imitated by hand-cutting, making your model more attractive, and making the design truly reach the realm of "not afraid of not being able to do it, but afraid of not thinking about it".
5. The powerful nesting and counting system can achieve automatic nesting and accurate counting, so as to accurately calculate the cost, accurately control the material distribution, and truly realize the digital zero inventory strategy.
5. The leather contour can be captured by projector projection or camera shooting, which can effectively identify leather defects. According to the natural texture of the leather, the cutting direction can be adjusted arbitrarily to increase the yield and reduce the loss, thereby improving the effective utilization of the material. Through the computer to accurately simulate each operation process, the program operation can be realized, and the traditional cutting of the material due to the emotions and skills of the workers Interference from personal factors such as fatigue, fatigue, etc., to avoid hidden waste, thereby increasing material usage.
7. It is possible to modify the template in time, save the time of developing the board, quickly release the board, quickly change the board, and adapt to the rapidly changing market demand.
8. The same board adjustment can be 2-3 days ahead of competitors, helping you quickly seize market opportunities.
Applications
Cutting material: cloth/leather/PVC/EVA/rubber/carbon fiber
Application industry: automotive supplies/clothing/sofa/plush fur/model
Application industry: automotive supplies/clothing/sofa/plush fur/model
Daily maintenance:
Cleaning of the guide rail (recommended to clean once every half month, shut down operation): The guide rail and linear axis are one of the core components of the equipment, and their function is to play a guiding and supporting role. In order to ensure the high processing accuracy of the machine, the guide rails and straight lines are required to have high guiding accuracy and good motion stability. During the operation of the equipment, due to the large amount of corrosive dust and smoke generated during the processing of the processed parts, these smoke and dust will be deposited on the surface of the guide rail and linear shaft for a long time, which has a great impact on the processing accuracy of the equipment, and will Corrosion spots are formed on the surface of the linear axis of the guide rail, which shortens the service life of the equipment. In order to make the machine work normally and stably and to ensure the processing quality of the products, the daily maintenance of the guide rail and linear axis must be done carefully.
Note: Please prepare for cleaning the guide-dry cotton cloth, lubricant
The guide rails of the cloth cutting machine are divided into linear guides and roller guides. In the YM series, linear guides are used in X direction and roller guides are used in Y direction.
Cleaning the linear guide: first move the laser head to the far right (or left), find the linear guide as shown in the figure above, wipe it with a dry cotton cloth until it is bright and dust-free, and add a little lubricating oil (sewing machine oil can be used, cutting Do not use engine oil), slowly push the laser head from side to side several times to distribute the lubricant evenly.
Cleaning the roller guide rail: Move the beam to the inside, open the end covers on both sides of the machine, find the guide rail as shown in the figure above, wipe clean the areas where the guide rails on both sides are in contact with the rollers with a dry cotton cloth, and then move the beam to clean the remaining areas.
Cleaning of the guide rail (recommended to clean once every half month, shut down operation): The guide rail and linear axis are one of the core components of the equipment, and their function is to play a guiding and supporting role. In order to ensure the high processing accuracy of the machine, the guide rails and straight lines are required to have high guiding accuracy and good motion stability. During the operation of the equipment, due to the large amount of corrosive dust and smoke generated during the processing of the processed parts, these smoke and dust will be deposited on the surface of the guide rail and linear shaft for a long time, which has a great impact on the processing accuracy of the equipment, and will Corrosion spots are formed on the surface of the linear axis of the guide rail, which shortens the service life of the equipment. In order to make the machine work normally and stably and to ensure the processing quality of the products, the daily maintenance of the guide rail and linear axis must be done carefully.
Note: Please prepare for cleaning the guide-dry cotton cloth, lubricant
The guide rails of the cloth cutting machine are divided into linear guides and roller guides. In the YM series, linear guides are used in X direction and roller guides are used in Y direction.
Cleaning the linear guide: first move the laser head to the far right (or left), find the linear guide as shown in the figure above, wipe it with a dry cotton cloth until it is bright and dust-free, and add a little lubricating oil (sewing machine oil can be used, cutting Do not use engine oil), slowly push the laser head from side to side several times to distribute the lubricant evenly.
Cleaning the roller guide rail: Move the beam to the inside, open the end covers on both sides of the machine, find the guide rail as shown in the figure above, wipe clean the areas where the guide rails on both sides are in contact with the rollers with a dry cotton cloth, and then move the beam to clean the remaining areas.
