220/110V 45mm 40n.m torque electric awning tubular motor

Product Overview

Description





WY45-40S AC Tubular motor

1.The detail information

Model	WY 45-40S	WY 45-40S
Rated Torque(N.m)	40	40
Rated Speed(rpm)	12	14
Rated Power(W)	260	260
Rated Current(A)	1	1.4
Running Time(min)	>4	>4
Limit Rating(turn)	30	30
Complete Length(mm)	610	610
Complete Weight(KG)	2.7	2.7
Rated Voltage(V)	220-230	100-110
Rated Frequency(Hz)	50	60
Tube Diameter(mm)	45	45















2.The accessory:





3. The package:
Every one seprate packed in a box; 10 boxes in one carton.
The box dimension: 600*75*75mm
The outer carton dimensions: 660*450*200mm

4. The usage: it usually can be used for the electric awnings, blinds, roller shutters and so on.



5. The Warranty:  we promise 5 years !

 All of them have passed CE certificate . So you can rest assured the goods quality . the warranty is 5 years .  If the tubular motor cannot work normally during the 5 years , we promise we will resend you new ones free of charge .









.Welcome to visit us. Any question , just feel  free to tell me…
