Automatic PVC Chewing Gum Blister Packaging Packing Machine for Tablets
- Category: >>>
- Supplier: Hangzhou Shengde Machinery Co. Ltd.
Share on (1600151179136):
Product Overview
Description
Machine Description
This automatic blister packing machine adopts international popular materials with good sealing, anti-moisture, protecting from light, using a special cold forming. It is new equipment in the pharmaceutical industry, which combines both functions, Alu-Alu and Alu-PVC by changing molds.
Product Paramenters
Model | DPP-140E | ||||
Double Functions | ALU ALU | ALU PVC | |||
Cutting Frequency | 15-30 times/min | 20-45 times/min | |||
Max. Forming Area and Depth | 140*110*12 | 140*110*15 | |||
Adjustable Scope of Travel | 30-120mm | ||||
Packaging Material(I.D.Φ75) | PVC (mm) | (0.15-0.4)*150*(Φ350) | |||
PTP (mm) | (0.02-0.15)*150*(Φ250) | (0.02-0.15)*150*(Φ250) | |||
Alu Alu Foil (mm) | (0.14-0.18)*150*(Φ350) | ||||
Paper (mm) | (50-100)g/m2*150*(Φ300) | ||||
Power | 380V 50Hz 4.5kw | 380V 50Hz 8kw | |||
Air Compression (self-prepared) | ≥0.45m³/min Pressure: 0.6-0.8Mpa | ||||
Cooling | Recycle water or circulating water consumption: 60-100L/h | ||||
Overall Dimension (L*W*H) | 2400*650*1450 (including foundation) | ||||
Dimension of Each Part | 1350*650*1250 (front) | ||||
1050*650*1450 (back) | |||||
Weight | About 800kg | ||||
Main Features
1- The main motor adopts an inverter speed controlling system.
2- Adopting a newly designed double hopper feeding system with high-precision optical control to realize automatic and efficient feeding. It is suitable for different blister boards and irregularly shaped objects.
3- Use an independent guiding track. The mold is fixed in a trapezoid shape, which is convenient for removal and adjusting.
4- Once the materials are used up, the machine will automatically stop running. It is also equipped with an emergency stop to ensure the safety of workers when operating the machine.
5- Organic glass cover is optional.
2- Adopting a newly designed double hopper feeding system with high-precision optical control to realize automatic and efficient feeding. It is suitable for different blister boards and irregularly shaped objects.
3- Use an independent guiding track. The mold is fixed in a trapezoid shape, which is convenient for removal and adjusting.
4- Once the materials are used up, the machine will automatically stop running. It is also equipped with an emergency stop to ensure the safety of workers when operating the machine.
5- Organic glass cover is optional.
Final Product
