300л Электрический медный Джин дистилляционное оборудование Moonshine

Share on:

Price:18 000,00 $ - 19 000,00 $
Price in USD:Details


Product Overview


300L Electric Copper Gin Distillery Distillation Equipment Moonshine
Customized Distiller for Gin, vodka, whiskey, rum, brandy, tequila from 200L to 20,000L .Fast Delivery.20 years of manufacturing experience. Contact Us For The Offer!


Products Description

We Can Make The Brewing Equipment For Beer, Wine, Sparkling Wine ,Whiskey,Gin, Brandy, Rum Etc
The Equipment Capacity From 200L To 20,000L.
Beer Equipment: Including The Brewhouse,Fermenter , Brite Tank , Mash Tun,Cip Trolley Etc;
Wine Equipment: Including The Red Wine/White Wine/Sparkling Wine Tank , Floating Lid Wine Tank And Whole Wine
Distillation Equipment: Including The Rum/Whiskey/Brandy/Gin/Vodka Stills

Material: T2 Copper/SUS304 for choose
Heating method: by steam/electrical heating elements
Top of pot with whole glass manway,inlet,safety valve, thermometer,pressure gauge and liquid return back hole. Top with agitator can be used to distill any wash,even washes full of fruit pulp or grain mash can heated in this configuration of boiler without any risk of burning on bottom of pot.Also,by constantly agitating the wash throughout the distillation run,the distillery can save 20% on the heating required to perform the distillation.

Spirit Type
Whisky Distiller
Still pot, swan neck, condenser,CIP, pipe system
Vodka Distiller
Still pot, onion head, column, dephlegmator,condenser,CIP, pipe system
Brandy Distiller
Still pot, onion head, column, dephlegmator, condenser, CIP, pipe system
Rum Distiller
Still pot, column, condenser, CIP, pipe system
Gin Distiller
Still pot, column, gin basket, condenser, CIP, pipe system
Multi-spirits Distiller
Still pot, onion head, column, gin basket, dephlegmator, conderser, CIP, pipe system

Product Name:
Distilling Equipment
Heating Mode:
Electric / Gas / Steam
SS304 / T2 Copper
boiler, distillation column, dephlegmator, condenser, proofing parrot,control box,heating rod.
We can customize the Distilling Equipment according to your requirements.

With Gin Basket
1. It is suitable for gin, schnapps etc. , add botanicals for making gin, enhance flavor and extand the function range of the system.

2. Material: stainless steel/ glass/ red copper.

3. Structure: outside with glass/ SS304 column, inside with removable copper filter basket.

This kind of equipment can be used for moonshine distilling of vodka, gin, whiskey, brandy, Milk Heating. They occupy small room space, and can be operated easily. The investment is also very small. These micro stills must be your best choice if you want to distill good spirits for your families, or want to start a business of small distillery.

Product Name:
Heating Mode:
Electric / Gas
SS304 / Red copper
boiler, distillation column, dephlegmator, condenser, proofing parrot,control box,heating rod.
RTS default configuration:
50 liter boiler, 4 stage 4 inch distillation column, dephlegmator, reducer elbow, 2 inch condenser, proofing parrot, electric
heating rod 4 kw, control box, clamps, gaskets etc.
materials are ss304, only bubble caps plates are red copper.
We can customize the Distilling equipment according to your requirements.

Customer case

Brewing equipment

Beer Fermentation Tank
• Beer Fermentation Tank has 200L and 30,000L and otherpecifications, according to the actual requirment of customers.

• Cone bottom shape, cooling jacket using dimple jacketjacketed outside covered with insulation, thermal insulationmaterial for polyurethane (cold).

• Connector using tri-clamp, inner tank using SS304 or S316L the inner surface mirror polishing Ra≤0.4um-0.6um. Outersurface can be polished, wiredrawn, sandblasted according tocustomers requirement.

Stainless steel beer fermenter
1.Volume from 100L-30000L,could be customized according to customer needs.
2.Material use sanitary stainless steel.
3.Three layer structure:Inner body,Jacket and isolation.Isolation layer filled with insulation material.
4.Inner wall fineness less than 0.6um,outside finish could be matt or mirror polish
5.Conical bottom shape,cooling jacket could adopt dimple jacket,arched and corrugated access jacket.
6.All pipes are all ISO or DIN sanitaty pipe,internal and external adopt food grade mirror polish
7.PLC control system,which could achieve automatic,semi automatic control,to ensure the accurately and effectively of parameters
and experimental results.
1.Manhole 2.Aseptic breather 3.Thermometer(As customer request) 4.CIP Spray ball 5.Bacterial access port 6.Agitator 7.Adjustable
leg 8.Jacket(Dimple or full jacket as customer request)

Bright Tank
The bright tanks are cans for storing live beer. After the beer is fermented and matured, the yeast and another turbidity in the fermentation broth need to be filtered to make the wine clear and bright. After the fermentation broth is filtered, it is called "bright beer". Let the packaging department bottling into beer finished products. Sake jars are used to hold sake.
In most breweries, the beer will be filtered after leaving the larger container and sent into bright tanks. If you want to force carbonation of bright beer, the beer can be carbonated in a fermentation tank or storage tank. In this case, the beer should be completely filled with carbonic acid to reach the bright tank.


Wine Fermentation Tank
1. Used as storage and fermentation tank in wine industries

2. Volume from 50L-30000L, could be customized according to customer needs

3. Material use sanitary stainless steel.

4. Conical bottom shape, cooling jacket could adopt dimple jacket, arched and corrugated access jacket.

5. PLC/PID control system, which could achieve automatic, semi-automatic control, to ensure the accurately and effectively of
parameters and experimental results.

Fermentor with agitator
Flat Bottom Wine Fermenter

Packaging & Shipping

We are experienced in the whole packing and shipping process,and we will be responsible for any damage made during shipping and send clients replacements for free.
* Sufficient inner protection with different materials, including bubble bag, foam board and others.
* Qualified wooden package or carton for different products or as customer require
* Strict packing process to ensure the safety and completeness of the goods



Q1. What is your terms of packing?
A: Generally, we pack our goods in plywood case or carton package for small parts.
If you have legally registered patent, we can pack the goods in your branded boxes after getting your authorization letters.

Q2. What is your terms of payment?
A: T/T in advance, 30% as deposit, and finish 70% balance payment before delivery.
We'll show you the photos of the products and packages before you pay the balance.

Q3. What is your terms of delivery?

Q4. How about your delivery time?
A: Generally, it will take 3 to 4 weeks after receiving your advance payment. The specific delivery time depends
on the items and the quantity of your order.

Q5. Can you produce according to the samples?
A: Yes, we can produce by your samples or technical drawings.

Q6.Do you test all your goods before delivery?
A: Yes, we have 100% test before delivery

Q7: How do you make our business long-term and good relationship?
A:1. We keep good quality and competitive price to ensure our customers benefit ;
2. We respect every customer as our friend and we sincerely do business and make friends with them, no matter where they come from.
