Hot sale pcb design and reverse engineering for induction cooker and pcb design mobile charger circuit board

Share on:


Price:
Price in USD:Details

Quantity:


Product Overview

Description






Product Description


al PCB board.jpg
































































































NoItemSpecifications
1Min.Track Width0.2mm(8mils)
2Min.Track gap0.2mm(8mils)
3Min.SMD pad pitch0.2mm(8mils)
4Product TypeAL Clad PCB 1layer~2layer
5Maximum Panel Size20''*24''(1170*600mm)
6Copper thickness0.5oz ~ 4oz
7Dielectric Thickness (To Substrate)0.05mm-2mm
8Substrate Core Thickness0.4mm-3.2mm
9Finished Board Thickness0.4mm-4.0mm
10Thickness Tolerance+/-10%
11Min.Finish hole size0.25mm
12 Soldermask colorWrite, Black, Others Available
13Reference StandardIPC-A-600G Class 2
14Special HolesSpot facing, Cup holes
15Surface FinishingHASL, HASL Leadfree, Immersion gold, Flash gold, OSP
16Max.working voltage2.5KVDC(0.075mm Dielectric), 3.75KVDC(0.15mm Dielectric)
17Data InputGerbers, AutoCad, Cam350, PROTEL 99SE, PROTEL DXP, POWER PCB, ODB+.(TGZ)










Company Information


 JY-company


Founded in 2009, Dalian Jiayuan Electronic Technolopy Co.,Ltd. has rich experience in multilayer PCB and single or double sided PCB assembly. Backed by our advanced techniques and experienced production staff, JY makes sure that all the layers in the multilayer PCB are perfect insulated between each other and every conductor pattern functions well. The R&D team in JY does a wonderful job and we can provide PCB products to our customers according to their design or requirements. All our products, including PCB, are passed the certification of SGS, TS, RoHS


Dalian JY can also manufacture and supply Aluminum PCB, Flexible PCB, fast PCB and the PCB/PCBA design and copy service to our customers.


- .jpg






 JY has established collaborative relationship with many customers worldwide. Now we are looking forward to cooperate with global customers. You can contact us for more detailed information.


Professional Printed Circuit Board Manufacture/ OEM SMT PCB Clone





Chinese goods Exhibition of  Mumbai India, we met many clients from india, Sri Lanka, Pakistan and other countries. Thanks for their trust and we already built long term business ship. We will do our best along the time for our partners.


 .jpg






Our Services


 HTB1UjvYQFXXXXXfXVXXq6xXFXXXO (1)





Our Factory


AL PCB.jpg


Aluminium PCB
1. Aluminium PCB Circuit Layer
The circuit layer (commonly used electrolytic copper foil) is etched to form the printed circuit, Compared to FR4 material, Aluminium PCB can bear higher electric current when same thick circuit layer and same trace width.
2. Aluminium PCB Insulating Layer /Dielectic Layer
The insulating layer is the core technology of the Aluminium PCB, which mainly serves as the function of adhesion, insulation and heat conduction.
The better the thermal conductivity of insulation is, the quicker the components spread the heat when they work, which can realize the purpose like improving power loading of the modules,reducing volume, extending life span and increase the output power.
JY has rich experience in manufacturing aluminium PCB with high thermal conductivity.
3. Aluminium PCB Metal Base Layer
Usually, considering the cost and technical characteristic, aluminium is the ideal choice. The available aluminum plates are 6061,5052,1060 etc.
If there is a higher heat transfer performance, mechanical properties, electrical properties and other special performance requirements, copper, stainless steel plate, iron plate, silicon steel plate, etc can also be used.








Packaging & Shipping





Packaging:


Our company is not only trying to give customers a good product, but also pay attention to offering a complete and safe package. And here we prepare some personalized services for all the orders.


Common packaging:


PCB: Sealed bag, Anti-static bags, Suitable carton.


PCBA: Antistatic foam bags, Anti-static bags, Suitable carton.


Refular Cartons Specification.





















No.Dimension(L*W*H)
small size33cm*28.5cm*18.5cm
medium size44.5cm*30cm*15cm
big size51.5cm*32.5cm*17.5cm

Customized Cartons: Carton outside according to the requirements of customers printed the name of the customer address, mark, the customer needs to  specify the destination and other information. Our Common Packaging Process.

package

JY-Shipment
