Solar Metal Construction Galvanized Steel Earth Screw Pile Bracket Fence Anchor Ground Screw
- Category: Screws >>>
- Supplier: Qingdao,Wangbaoqiang,Industry,Co.,Ltd.
Share on:
Product Overview
Description
Product Description
1. Solar Metal Construction Galvanized Steel Earth Screw Pile Bracket Fence Anchor Ground Screw
FAQ
WBQ FM TYPE
| Specification | Material | Length mm | Diameter mm | Thickness mm | Flange Outer Diameter mm | Flange
Thickness mm | Screw Pitch mm | Screw thickness mm | Spiral Width mm |
WBQ FM76X1300/1600/2100-M16 | Q235/Q345 | 1300/1600/ 2100 | 76 | 3-4 | 182 | 8 | 60 | 2-3 | 10-20 |
WBQ FM89X1300/1600/2100-M24 | Q235/Q345 | 1300/1600/ 2100 | 89 | 3-4 | 182 | 10 | 60 | 2-3 | 10-20 |
WBQ FM114X1300/1600/2100-M24 | Q235/Q345 | 1300/1600/ 2100 | 114 | 3-4 | 182 | 10 | 60 | 2-3 | 10-20 |
| WBQ FM140X1300/1600/2100-M16 | Q235/Q345 | 1300/1600/ 2100 | 140 | 3-4 | 225 | 10 | 60 | 2-3 | 10-20 |
Type of finish available:
1.Hot -dip galvanized
2.Electro galvanized
3.Powder coated
2.Picture of Product newsunpower screw ground anchor
Packaging & Shipping
Our Services
*Easy Installation: Our versatile rail, Uisolar SolarRoof module and splice kit eliminates the need for onsite cutting, making Solar Roof a safe and cost effective solution.
*Versatile Application: With a full range of roof hooks, Uisolar SolarRoof is suitable for most roof types, including pitched tile roofs, metal roofs, concrete roofs, and even slate roofs.
*Great Compatibility : Designed as a universal racking system, Uisolar SolarRoof is compatible with most of the major framed and frameless PV modules on the market.
*High Quality: Strict quality control over materials and finished products ensure optimum strength and long life for your installation.
*10-Year Guarantee:
A 10-year limited guarantee sets you free from worries about maintenance.
*Quick response: the inquiry will be replied with 24 hours.
*Customized design: we are professional solar racking system solution designer and manufacturer, with 10 years' solution database.
