ONILAB RCT340 S4 LCD Thermostatic Digital 4 Channel Hotplate Magnetic Stirrer
ONILAB RCT340-S4 LCD Thermostatic Digital 4-Channel Hotplate Magnetic Stirrer

ONILAB RCT340 S4 LCD Thermostatic Digital 4 Channel Hotplate Magnetic Stirrer

Share on (1600157228653):


Price:

Quantity:


Product Overview

Description



Product Description


ONILAB RCT340-S4 LCD 4-Channel Thermostatic Digital Hotplate Magnetic Heater
It is widely used in chemical synthesis, physical and chemical analysis, biopharmaceuticals etc.


Feature:
• Independent heating and stirring control.
• LCD display shows actual temperatures and speed.
• PID controller ensures a precise and steady heating process, Max temperature up to 340℃
• Brushless DC motor enables more powerful speed control.
• External temperature sensor(PT1000) with accuracy at 0.2℃.
• Overheating protection temperature at 420℃.
• Stainless steel work plate with ceramic coating provides good chemicalresistant performance.
• A wide variety of accessories are available.


Specification


Work plate dimension
Φ135mm（5inch）
Plate material
Stainless steel with ceramic coating
Motor type
Brushless DC motor
Motor rating input
1.8W×4
Power
515W×4
Heating Power
500W×4
Voltage
100-120V, 60Hz; 200-240V, 50Hz
Stirring positions
4
Max. stirring quantity of single position (H2O)
10L
Max. magnetic bar
40mm
Speed range
200-1500rpm
Speed display
LCD
Temperature display
LCD
Control accuracy of sensor
±20rpm
Temperature range
25-340℃
Over temperature protection
420℃
Temperature display accuracy
±0.1℃
External temp. sensor
PT1000 (Accuracy±0.2℃)
IP Protection class
IP21
Dimensions [WxDxH]
698×270×128mm
Weight
9.5kg
Permissible ambient temperature
5～40℃
Permissible relative humidity
80%RH
