2. Kaby Lake 14nm CPU Intel Core i5 7267U 2 cores 4 threads 3.1GHz up to 3.5GHz 4MB cache TDP 28W Intel Iris Plus Graphic 650.
3. Skylake 14nm CPU Intel Core i7 6500U 2 cores 4 threads 2.5GHz up to 3.1GHz 4MB cache TDP 15W Intel HD Graphic 520.
4. Kaby Lake R 14nm CPU Intel Core i5 8250U 4 cores 8 threads 1.6GHz up to 3.4GHz 6MB cache TDP 15W Intel UHD Graphic 620.
5. Kaby Lake R 14nm CPU Intel Core i7 8550U 4 cores 8 threads 1.8GHz up to 4.0GHz 8MB cache TDP 15W Intel UHD Graphic 620.
Specification
Processor
Core i7-8550U
Speed
1.8~4.0GHz, 8/MB Cache
Processor number
4core / 8threads
Technique
14nm
Graphic Cards
Intel UHD Graphics 620
Graphics Base Frequency
300MHz
Max Dynamic Frequency
1.15 GHz
Resolution (MAX)
4096x2304@24Hz(HDMI)
Operating System
Default: Windows 10; Optional: Windows 8.1/ Windows 7/ Linux Ubuntu
Storage
32GB/64GB/128GB/256GB/512GB SSD; 500GB/1TB HDD available
RAM
DDR4 1*Solt
Audio Cards
ALC662 sound chip, 6-channel
Network card
RTL8111DL PCI-E Gigabit Ethernet NIC
Ethernet
10/100/1000mbps BaseT LAN
WIFI
dual antenna, 802.11.b/g/n 300M
Display port
1* HDMI,1*VGA,1*SP2,4G SIM solt (don't include the SIM Card,pay extra money )
USB port
4 * USB3.0, 4 * USB2.0
Ethernet port
2* RJ45 Intel i211 10/100/1000Mbps Adaptive
Industrial Port
6* RS232 COM Port COM1 COM2 support RS232 422 485
Power input port
1 inner diameter 2.5mm, external diameter 5.5mm
Audio
Standard 3.5 Audio input and output
Power Input
DC100-240V AC/50-60Hz
Power Output
DC 12V/6A
Power Type
External power adapter mode
Consumption
15-25W
Noise
Fanless System
Temperature
0-95 Centigrade
Humidity
10%-90%
Size
230*175*50mm
Case Thickness
2.9MM
Package Box
Neutral Color Export Box / Plain Box
Content
Mini Computer, Power Adapter, Power Cable, screws, WiFi Antennas
Packing & Delivery
✈✈Actual delivery time: most customers receive within 7-15 working days. 1. All items will be double checked and well packed and they will be dispatched within 5 business days when order is paid. 2. Normally we ship package by DHL, it will take about 3~7 working days to most of countries, door to door. 3. If you address is a remote area by DHL, if you do not add remote area shipping fee, we will arrange shipment by our methods,hope you can kindly understand it, thanks. 4. e-EMS: it is for Russia and some other countries. 5.If you choose the shipping way is air post mail , it normally takes 30-90 days without tracking information , pls noticed. It's better to choose EMS or DHL , more faster and safe . 6. If you don't get the package in normal time, please contact us kindly, we will do our best to assist you. 7. If you don't accept above terms, pls do not buy it, thanks.
Company Profile
Shenzhen Inctel Technology Co.,Ltd. has established cooperation with lots of enterprises, rely on its strength, reasonable price,excellent service, over 10 years rich experience in R&D and producing. Products are popular at home and abroad. Its OEM/ODM services have already covered many countries in South East Asia, Middle East, Europe, America, South Africa etc.
1. As a professional manufacturer and supplier of mini pc over 10 years,we win our customers with good quality,best service and competitive price. 2.Our products are 100% original and have strict QC inspection before shipment. 3.Professional and efficient sales team serve for you diligently 4.Sample order is welcomed and will be delivered within 3 days. 5.We are Alibaba assessed 7 years Gold Supplier and more than 10 years industrial experience. 6.We support Trade Assurance to ensure On-time shipment and product quality. 7.We provide OEM service according to your requirements. 8.We provide 3 Years maintenance warranty for our products.
1. Can you put my brand name (logo) on these products? Yes,.We can support OEM/ODM service, the process of customization is following: 1) provide your specific requirement. 2) our design engineer draw the design draft. 3) you confirm the design draft. 4) we start produce it.
2. What payment method do you accept? T/T, Western Union, PayPal, Escrew, Alibaba Trade Assurance order payment; Money Gram, Cash, L/C, etc.
3. What is the Minimum Order Quantity (MOQ)? We can sell one piece of sample for your testing.
4. What is the lead time of your products? 1-2 days for one sample, 7-15 working days for a large quantity.
5. How many years for the product warranty? 3 years, we have a professional team work for after-sales services, please kindly feel free to contact us if any questions.
6. What are the shipping methods for it? We can ship by International express, like DHL, UPS, Fedex, TNT, etc; or by Air/ Sea, etc.
7. What kinds of customization can you do? We can do the products as per your configuration of CPU, RAM, hard disks, WiF, I/O ports, color, size, customized OS, logo, etc.
8. Can you equip the devices with related products or services? Yes, we can offer you mouse and keyboard combo, HDMI cable, genuine Windows 10 license, external CD-ROW, USB Hub, Bluetooth dongle, etc.
9. What is HS code of Partaker mini pc? 8471494000
