Share on (1600166991240):


Price:$29.00 - $34.00

Quantity:


Product Overview

Description



Product Description




Specification


Brand
YUCOO
Model Series
YK-CD XX YY
XX--Output Voltage; YY--Output Current
Model list
YK-CD1240
YK-CD2440
YK-CD3635
YK-CD4825
YK-CD6020
YK-CD7217
Input Voltage
1 phase 200-240Vac Input
Frequency
50/60hz
Output Voltage
12V
24V
36V
48V
60V
72V
Output Current
40A
40A
35A
25A
20A
17A
Rate Power
480W
960W
1260W
1200W
1200W
1224W
Shell
Aluminum Alloy Shell
N.W/GW
4 kg/5 kg
Product dimension
208*130*107mm
Package dimension
47*28*15.5cm/1pc
Suitable battery Type
Lead Acid / LiFePO4 /Li-ion
Lipo battery voltage is 4.2V
LiFePO4 battery voltage is 3.65V
Lead acid battery voltage is 14.7V
Equal voltage
(Lead acid)
14.7V
29.4V
44.1V
58.8V
73.5V
88.2V
Float voltage
(Lead acid)
13.8V
27.6V
41.4V
55.2V
69V
82.8V
LiFePO4/3.65V
Charge voltage
14.6(4s)
29.2(8s)
43.8(12s)
58.4(16s)
73(20s)
87.6V(24s)
Lipo/4.2V
Charge voltage
(S-Connect in series)
12.6(3s)
16.8(4s)
25.2(6s)
29.4(7s)
42/4.25(10s)
50.4(12s)
54.6(13s)
58.8(14s)
63.0(15s)
67.0(16s)
71.4(17s)
84V(20s)
Charging Principle
Full automatic transition CC,CV and Float/Cut-off
Charging Time
Cut-off point for Li battery is 5% of CC and it can be set between 3-10%.（charging time:4 hours）
Transition for Lead acid charger is 20% of CC.（charging time:6-8 hours）
High-Efficiency
≥90%
MTBF
≥50000h
Dielectric Strength
Input to shell ≥AC1500V
Input to output ≥AC1500V
Output to shell ≥AC500V
Operating Temperature
-20℃~50℃
Store Temperature
(-40～70)℃
Related humility
90％(40±2℃)
Protection Function
Over voltage / Over temperature / Over current/Short circuit and Reverse polarity Protect
Display
Two LED indicators
Advantage
Light/Small/Stable/Safe
AC Plug
Accept any plug base on your request
Warranty
1 year Warranty
