Application -86°C ultra-low temperature freezers are designed for long term preservation of virus, germs, vaccines, biological tissues and organs, special food, medicines, reagents, etc.
Features ■ Accurate temperature controller, setting temperature range is -40 ~ -86°C, accuracy is 0.1 °C. ■ Suggested ambient temperature: +10~32°C. ■ Insulated inner door to ensure good temperature uniformity. ■ 304 SS inner chamber and round corner for friendly using and easy cleaning. ■ Special designed structure for sample storage. ■ Wide available voltage range: 187V~242V.
Security ■ Safety door lock and controller setting password to prevent unauthorized access. ■ Build-in back-up battery to power control system for 72 hours when power failure. ■ Visual and audible alarm system: High/low temperature, power failure, sensor failure, door ajar, condenser clean, high ambient. ■ Power failure protection: turn on delay of the cooling system after power failure. ■ Controller error protection: the cooling system will remember the normal working cycle and keep working depending on this memory when controller or two sensors failed.
Humanized design ■ Casters with stopper for easy moving and fixation. ■ Adjustable shelves for easy storing. ■ Special designed service-free drainage system. ■ Condenser clean alarm to remind the user to clean the freezer regularly.
Optional parts ■ Test hole, Data logger, Chart recorder, LN2 back-up system, cold storage rack & box.
Specification
Model No.
MDF-86V588E
Performance
Temperature Range
-40 ~ -86°C
Ambient Temperature
+10 ~ 32°C
Controller
Microprocessor
Display
LCD
Noise
53 dB
Electrical Data
Power Supply
220V/50Hz
Rated Power
1500 W
Electrical Current
9.1 A
Power Consumption
16.5 kWh/24h
Refrigeration System
Compressor
SECOP * 2
Refrigerant
Mixed Refrigerant
Cooling Type
Direct cooling
Defrost Type
Manual
Alarm
High/Low Temperature
Y
High Ambient
Y
High/Low Voltage
Y
Sensor Error
Y
Condenser Error
Y
Door Ajar
Y
Low Battery
Y
Filter Clean
Y
Dimensions
Capacity
588 L
Interior Size(W*D*H)mm
606×738×1310
Exterior Size(W*D*H)mm
891×1155×1994.5
Package Size(W*D*H)mm
970×1138×2185
N.t./G.t.(approx.)
303/332 kgs
Accessories
Caster with Stopper
4
Inner Door(Foamed)
2
Shelf(304 SS)
3
Test Hole
25mm * 1
USB Port
1
※ Specifications are subject to change without notice. Performance data herein is based on independent testing at time of publication. For latest specification information contact our sales representatives.
