Application Medical mobile cooler are specially designed to store and transport blood, serum, plasma, vaccine, reagents and special medicines for epidemic prevention station, blood bank, health center, CDC, animal husbandry bureau, army and pharmaceuticals company.
Features
■ Accurate temperature control, the temperature accuracy is 0.1°C. ■ Integrated and strong PE body to resist impact and corrosion. ■ Smooth and flat surface for easy cleaning. ■ 60mm thickness CFC free foam layer to ensure good insulation performance ■ High efficiency air cooling system to ensure good temperature uniformity. ■ Temperature range: -25~+30°C (30L&80L), +22°C, +4°C (770L). ■ Auto switch cooling and heating system to ensure the inside temperature in all climatic conditions. ■ Wide voltage design, able to be used when the voltage is between 187V~242V AC and 12V/24V DC.
Security ■ Built-in protective basket to prevent the samples being frozen off by evaporator.■ PC lock for easy operation and good appearance. ■ Two power ports for AC/DC connection. ■ Equipped with protective fuse to avoid the destruction caused by overcurrent. ■ Able to be stacked, saving space.
Optional parts ■ Test hole, Water outlet, Data logger, blood basket.
Specification
Model No.
MBC-4V700LC
Performance
Temperature Range
+4~+22°C
Ambient Temperature
+10 ~ 32°C
Controller
Microprocessor
Display
LCD
Noise
50 dB
Electrical Data
Power Supply
220V/50Hz, 12V DC
Rated Power
160 W
Electrical Current
14 A(DC 12V)
Power Consumption
1.6 kWh/24h
Refrigeration System
Compressor
Chinese Brand * 1
Refrigerant
R134a
Cooling Type
Forced air cooling
Defrost Type
Auto
Alarm
High/Low Temperature
Y
Sensor Error
Y
Power Failure
Y
Dimensions
Capacity
700L
Interior Size(W*D*H)mm
939×973×863
Exterior Size(W*D*H)mm
1090×1129.5×1080
Package Size(W*D*H)mm
1140×1190×1150
N.t./G.t.(approx.)
265/335 kgs
※ Specifications are subject to change without notice. Performance data herein is based on independent testing at time of publication. For latest specification information contact our sales representatives.
