Evacuated tube solar collector with Heat Pipe

Share on:

Price in USD:Details


Product Overview


 Evacuated tube solar collector with Heat Pipe: SCM-01

Product Description


1. The pipeline is made of all the red copper and conducted by heat transfer medium liquid.

2. Water can't flow in vacuum tubes and operated when confined.

3. The manifold uses aluminum alloy mould material of high strength with airflow design;

4. It is furnished in good style;

5. Can withstand high pressure when it works;

6. Module design, arbitrary combination, which can meet the demand of large water consumption.


Working Principle


The selective coating on the inner tube converts solar energy into heat energy and transfers heat to the heat pipes by aluminum fins. The liquid in the heat pipe changes into vapour which rises to the condenser. The heat then passes through the heat exchanger and the vapour becomes liquid, returning to the bottom of the heat pipe. The heat conducts to the heat transfer liquid via a copper pipe. This transference of heat into the liquid creates a continuous circulation as long as the collector is heated by the sun.




Technical Parameters:

manifold (inner)red copper
manifold (exterior)aluminum alloy
glass tube dimensions58mm * 1800mm
daily efficiency≥55%
heat preservation72 hours
hail resistance25mm
max pressure7 bar
coating of vacuum tubeALN/AIN-SS/CU
heat pipeanti-freezing > -35 degree


Solar Keymark, EN12975


Series Products:

ModelsL*W*H (mm)Vacuum tubePower outputEfficiencyHeader mmCondenserFrameContainer loading 20FT/40HQ setsGross Weight (kg)


79.50%Φ35/1.0Φ14/1.0AL alloy146/35041
SCM15-011975*1225*135 58*1800*15pcs960W79.50%
Φ35/1.0Φ14/1.0AL alloy125/30556
SCM20-011975*1571*13558*1800*20pcs1280W79.50%Φ35/1.0Φ14/1.0AL alloy95/22964
SCM30-011975*2326*13558*1800*30pcs1930W79.50%Φ35/1.0Φ14/1.0AL alloy65/15795


Terms and conditions:


T/T with 30% deposit, balance against the copy of B/L

100% T/T in advance for sample

MOQ1 Set
Loading portShanghai / Ningbo
PackageStandard carton

7-10 days after payment for a sample

15-20 days after payment for container





Packaging & Shipping








Our Services


Pre-sale Service

1. Sample can be offered with sample charge and courier fee by buyer's side.

2. OEM and ODM order are accepted, any kind of logo printing or design are available.

3. Good Quality + Factory Price + Quick Response + Reliable Service, is what we are trying best to offer you.

4. All of our products are produced by our professional workman and we have our high-work-effect foreign

trade team, you can totally believe our service.

5. We have rich experience of design, manufacture, and sell solar water heaters.


After you choose

1. We will count the cheapest shipping cost and make an invoice to you at once.

2. Check quality again, then send out to you at 7 working day after your payment,

3. Email you the tracking no, and help to chase the parcels until it arrives you.


After-sale service

1. If you have any questions, please feel free to contact us by E-mail or Telephone.

2. Customer gives us some suggestions for price and products are highly appreciated.


Company Information


ZHEJIANG SHENTAI SOLAR ENERGY CO., LTD was established in 2000 year and covers an area of 36000 square meters. Suntask is a high-tech enterprise, specialize in manufacturing solar collector, solar water heater, photovoltaic system, air-source heat pump.
