High quality DC CCS Electric Vehicle Charging CCS2 EV Socket 200A Combo Fast Charger Connector
High quality DC CCS Electric Vehicle Charging CCS2 EV Socket 200A Combo Fast Charger Connector
High quality DC CCS Electric Vehicle Charging CCS2 EV Socket 200A Combo Fast Charger Connector
High quality DC CCS Electric Vehicle Charging CCS2 EV Socket 200A Combo Fast Charger Connector
High quality DC CCS Electric Vehicle Charging CCS2 EV Socket 200A Combo Fast Charger Connector
High quality DC CCS Electric Vehicle Charging CCS2 EV Socket 200A Combo Fast Charger Connector
High quality DC CCS Electric Vehicle Charging CCS2 EV Socket 200A Combo Fast Charger Connector

High quality DC CCS Electric Vehicle Charging CCS2 EV Socket 200A Combo Fast Charger Connector

Share on (1600171284591):


Price:$88.50 - $92.30

Quantity:


Product Overview

Description



Product Description




Socket type
CCS2 socket for EV
Current
16/32A AC; 200A DC
Voltage
240/415V AC; 1000V DC
Application standard
IEC62196-3-2016
Plug shell material
Thermoplastic (flame retardant grade: UL94-0)
Operational temperature
-30 °C to +50 °C
Vandalism-proof
No
UV resistant
Yes
Certificate
CE, TUV
Cable length
Customizable
Terminal material
Copper alloy, silver plating
Terminal temperature rise
＜50k
Withstand voltage
3200V
Contact resistance
≤0.5mΩ
Mechanical life
＞10000 times of off-load plug in/out
Coupled insertion force
Between 45N and 100N
Withstandable impact
Dropping from a 1m height and running-over by a 2-ton vehicle
Warranty
2 years
