Product Overview
Description
YH800B precision digital pressure gauge is mainly used to calibrate pressure (differential pressure) transmitters, ordinary (precision) pressure gauges. It is a pressure calibration instrument with single range, micro power consumption, and large screen wide viewing angle LCD display. Pressure gauges and precision pressure measurement; can be calibrated online through standard RS485, RS232, and USB interfaces for data processing.
MAIN FEATURE
Micro power consumption, low energy consumption, battery can work continuously for more than 1 year
Swiss imported chips, high reliability
LCD display is simple and atmospheric
Digital calibration without hardware adjustment
Ten pressure units are optional
Small size, simple operation, convenient for on-site calibration
With storage and peak recording functions
Common pressure range "selection table"
Measuring range | Measuring range | Measuring range | Measuring range | Measuring range | |
-100~0kPa | 0~40kPa | 0~600kPa | 0~6MPa | 0~40MPa | |
0~2kPa | 0~60kPa | 0~1MPa | 0~10MPa | 0~60MPa | |
0~5kPa | 0~100kPa | 0~1.6MPa | 0~16MPa | 0~80MPa | |
0~10kPa | 0~160kPa | 0~2MPa | 0~20MPa | 0~100MPa | |
0~20kPa | 0~250kPa | 0~2.5MPa | 0~25MPa | 0~160MPa | |
0~25kPa | 0~400kPa | 0~4MPa | 0~30MPa | 0~250MPa | |
TECKNICAL
With self-calibration, zero clear function
Multiple pressure unit switching
Working time: more than 1500 hours
Accuracy level: 0.02, 0.05, 0.1, 0.2, 0.4
Pressure range: single program (refer to the selection table)
Pressure category: gauge pressure, differential pressure, absolute pressure
Environmental temperature: -10~50℃
Relative temperature: ≤95%RH
Dimensions: (185×115×45) mm
Weight: about 0.5kg
