Измеритель внутреннего сопротивления батареи Kongter, портативный тестер сопротивления батареи

Product Name:

BT-301 Battery Condition Analyzer

Applications:

Test single Lead-Acid or Nickel-Cadmium cell or battery string (one by one after setting once).

Cell types supported:

1.2V, 2V, 6V, 12V and other customized types up to 6000Ah.

Voltage:

0.000V—25V DC

Resistance:

0.001 mΩ--100mΩ

Conductance:

100 - 19,990 Siemens

Test Data Storage:

100,000 cells stored internally, unlimited with USB drive exportation

Accuracy:

Resistance/Conductance: 2%

Voltage:

0.5%

Voltmeter Resolution:

1mV

User Programmable Functions:

Customized battery types
Low voltage alarm setting
High resistance alarm setting
Test mode (push button/touch screen/auto start)

Cable Options:

2-section Pin probe
Alligator Test Clamp
Custom cables by quotation

Power supply:

Li-ion battery (4000mAh), 8~12hours working time after full charge

Display:

272*480 pixel, 4.3”TFT Touch Screen LCD

Data Transfer:

USB

Operation Environment:

0~40℃, 90% relative humidity, non-condensing

Storage Temperature:

-20~50℃

Over Voltage Protection:

Auto-reset disconnect
Reverse polarity protected

Housing Material:

Acid resistant ABS plastic santoprene overmold

Tester Dimensions:

L186*W98*H40 mm

Analyzer Weight:

0.45KG

Shipping Weight:

Approximately 3.5Kg
