BYOND Health Care Manufacturer Price Hospital Automatic Medical Portable Elastomeric Anesth Infusion Pump Ce Electricity BYS 820
- Category: >>>
- Supplier: Hunan Beyond Medical Technology Co. Ltd.
Share on (1600181264710):
Product Overview
Description
Product Description
Features:
1. LCD Display, high capacity words, friendly user interface, dynamically display working status;
2.Female Voice alarm in English/Russian (other language is optional for customized machine)
3.Compatible with any brands of infusion sets after correct calibration;
4.Preset solution volume to greatly reduce the workload of nurses;
5.Work mode: ml/h and drop/min can switch freely;
6.Three levels of occlusion: high, middle and low;
7.Purge /Bolus function;
8.KVO (keep-vein-open) automatically opens as infusion is completed, KVO rate is 1ml/h---5ml/h (1ml/h step);
9.Automatically record the settings of last infusion;
10.BYS-820D can store 2000pcs of infusion records and has drug library with 1000durgs.
2.Female Voice alarm in English/Russian (other language is optional for customized machine)
3.Compatible with any brands of infusion sets after correct calibration;
4.Preset solution volume to greatly reduce the workload of nurses;
5.Work mode: ml/h and drop/min can switch freely;
6.Three levels of occlusion: high, middle and low;
7.Purge /Bolus function;
8.KVO (keep-vein-open) automatically opens as infusion is completed, KVO rate is 1ml/h---5ml/h (1ml/h step);
9.Automatically record the settings of last infusion;
10.BYS-820D can store 2000pcs of infusion records and has drug library with 1000durgs.
Company Profile
Founded in 2009, Hunan Beyond Medical Technology is a CE and ISO certified medical device manufacturer with a registered capital over 30 million RMB.
Beyond Medical owns workshop over 17000 m² with more than 300 staffs. It has 7 production lines, manufacturing a wide range of products, including syringe pump, infusion pump, CPAP & BPAP, HFNC, nurse call system and dental equipment. Benefiting from its own SMT workshop, all PCB boards are processed independently on site, therefore Beyond medical can provide customized and qualified products under its own control.
Adhere to “Quality and Technology Oriented” motto, Beyond Medical has absorbed an elite R&D team with more than 60 engineers. Over the years, Beyond Medical has accumulated over 50 patents and software copyrights. Taking care of product quality and after-sale service is in our blood, Beyond Medical is reputed as Chinese Trusted Brands in Medical Devices in Chinese market and exported to more 80 major countries overseas including USA, EU countries, Australia, Russia, Brazil, Saudi Arabia, Indonesia and India, etc. It has three sales teams to take care of marketing, sales, service and customer feedback, support languages with English, Russian, Spanish and Arabic.
Beyond Medical will always integrate its corporation culture of “simplicity, efficiency, honest and pleasant” into every aspects of management as well as production procedures, and dedicate in offering reliable, affordable products to all of our partners on long term development basis.
Beyond Medical owns workshop over 17000 m² with more than 300 staffs. It has 7 production lines, manufacturing a wide range of products, including syringe pump, infusion pump, CPAP & BPAP, HFNC, nurse call system and dental equipment. Benefiting from its own SMT workshop, all PCB boards are processed independently on site, therefore Beyond medical can provide customized and qualified products under its own control.
Adhere to “Quality and Technology Oriented” motto, Beyond Medical has absorbed an elite R&D team with more than 60 engineers. Over the years, Beyond Medical has accumulated over 50 patents and software copyrights. Taking care of product quality and after-sale service is in our blood, Beyond Medical is reputed as Chinese Trusted Brands in Medical Devices in Chinese market and exported to more 80 major countries overseas including USA, EU countries, Australia, Russia, Brazil, Saudi Arabia, Indonesia and India, etc. It has three sales teams to take care of marketing, sales, service and customer feedback, support languages with English, Russian, Spanish and Arabic.
Beyond Medical will always integrate its corporation culture of “simplicity, efficiency, honest and pleasant” into every aspects of management as well as production procedures, and dedicate in offering reliable, affordable products to all of our partners on long term development basis.
Specification
Model | BYS-820& BYS-820D |
Infusion Rate | ml/h mode:1~1200ml/h(1ml/h step) drop/min mode:1~266drop/min(1drop/min step) |
Purge Rate | 100mh/h---1200ml/h(can be calibrated) |
Flow Rate Accuracy | ml/h mode:Within±5%(after correct calibration) drop/min mode:Within±3%(after correct calibration) |
Mechanical Precision | Within±2% |
Maximum infusion pressure | 150kPa |
Alarm Pressure | High 800mmHg±200mmHg(106.7kPa±26.7kPa) Medium 500mmHg±100mmHg(66.7kPa±13.3kPa) Low 300mmHg±100mmHg(40.7kPa±13.3kPa) |
Audible and Visible Alarms | There are bubbles、Tube is blocked、Close the door、IV set Mismatched、Battery running out、Infusion finish、Equipment failure、Abnormally Operation、Software Exception、Low battery、 forget the operations etc |
Transport&Storage Condition | Temperature -20℃~+55℃ Relative Humidity £95% Atmospheric Pressure 50.10KPa---106.0KPa |
Infusion Set | Compatible with any brand of infusiong sets ater correct calibration The following brands of infusiong sets are recommended:GEA、Onemed、SHINVA |
Infusion maximum value (under single fault condition) | 1ml |
Forbidden | Not support blood Infusion |
Dimension | 140mm(L)´157mm(W)´220mm(H) |
Net Weight | 1.8kg |
Package Reference | 1pc Carton:2.8KG,33cm(L)×28cm(W)×26cm(H) 2pcs Carton:6.5KG,52cm(L)×30cm(W)×36cm(H) 3pcs Carton:9.6KG,76cm(L)×30cm(W)×36cm(H) |
FAQ
1. who are we?
We are based in Hunan, China, start from 2009,sell to Domestic Market(45.00%),South Asia(15.10%),Northern Europe(14.00%),Southeast Asia(8.00%),Eastern Europe(7.10%),South America(5.60%),Eastern Asia(2.00%),Mid East(2.00%),North America(0.70%),Western Europe(0.10%),Oceania(0.10%),Southern Europe(0.10%),Africa(0.10%),Central America(0.10%). There are total about 301-500 people in our office.
2. how can we guarantee quality?
Always a pre-production sample before mass production;
Always final Inspection before shipment;
3.what can you buy from us?
Infusion Pump,Syringe Pump,CPAP And BIPAP,Nurse Call System,Dental Equipment
4. why should you buy from us not from other suppliers?
BEYOND owns a strong R&D group of 15 software & hardware engineers and a 30 marketing & after-sales service team.
BEYOND has got the ISO9001, ISO13485, FSC, CE, GOST etc. Certificates.
Good Quality Control with Competitive Selling Prices.
5. what services can we provide?
Accepted Delivery Terms: FOB,CFR,CIF,EXW,FAS,CIP,FCA,CPT,DEQ,DDP,DDU,Express Delivery,DAF,DES；
Accepted Payment Currency:USD,EUR,JPY,CAD,AUD,HKD,GBP,CNY,CHF;
Accepted Payment Type: T/T,L/C,Credit Card,PayPal,Western Union,Cash;
Language Spoken:English,Chinese,Spanish,Japanese,Portuguese,German,Arabic,French,Russian,Korean,Hindi,Italian
We are based in Hunan, China, start from 2009,sell to Domestic Market(45.00%),South Asia(15.10%),Northern Europe(14.00%),Southeast Asia(8.00%),Eastern Europe(7.10%),South America(5.60%),Eastern Asia(2.00%),Mid East(2.00%),North America(0.70%),Western Europe(0.10%),Oceania(0.10%),Southern Europe(0.10%),Africa(0.10%),Central America(0.10%). There are total about 301-500 people in our office.
2. how can we guarantee quality?
Always a pre-production sample before mass production;
Always final Inspection before shipment;
3.what can you buy from us?
Infusion Pump,Syringe Pump,CPAP And BIPAP,Nurse Call System,Dental Equipment
4. why should you buy from us not from other suppliers?
BEYOND owns a strong R&D group of 15 software & hardware engineers and a 30 marketing & after-sales service team.
BEYOND has got the ISO9001, ISO13485, FSC, CE, GOST etc. Certificates.
Good Quality Control with Competitive Selling Prices.
5. what services can we provide?
Accepted Delivery Terms: FOB,CFR,CIF,EXW,FAS,CIP,FCA,CPT,DEQ,DDP,DDU,Express Delivery,DAF,DES；
Accepted Payment Currency:USD,EUR,JPY,CAD,AUD,HKD,GBP,CNY,CHF;
Accepted Payment Type: T/T,L/C,Credit Card,PayPal,Western Union,Cash;
Language Spoken:English,Chinese,Spanish,Japanese,Portuguese,German,Arabic,French,Russian,Korean,Hindi,Italian
