ZJR 30 Factory Price Stainless Steel Vacuum Emulsifying Mixer Jam Making Machine Sauce Production Line
- Category: >>>
- Supplier: Wuxi YK Automation Technology Co. Ltd.
Share on (1600183201372):
Product Overview
Description
Product Description
ZJR-30 Strawberry Jam Making Line Machines
ღ Features:The pot cover is automatic lift type, the material was directed draw into the emulsifying boiler from oil boiler and water boiler based on a pipe that is under vacuum, the discharge is based on the turn the emulsifying boiler. And the heating system is electric heating or steam heating that the temperature is automation control. Put the cool water into the intercalated bed so cooling the material, simple operation and safety( at the outside have a warm layer). The homogenizer and the blade stirring can together work or separate work. The material sliming, emulsification, mixing, dispersing, etc. what will finished during short time. Contact position adopt high-quality stainless steel (medical use adopt 316L material make with supplies, polish mirror of interior surface, mix the hygiene of the device in vacuum, it accords with the normal hygiene standard manufacture of GMP to adopt that is most ideal production equipment.
mayonnaise making machine
ღ Application:
Working Principle
There are three pots : Main pot (Emulsifying pot) and preparatory pots (Water pot and Oil pot).
The water pot and oil pot are preparatory pots. For products which need emulsifying, the raw materials are always including water phase material and oil phase material, so the water pot is for preparation of water phase materials, and oil pot is for preparation of oil phase materials. The two pots both have jacket layer, which can be heated by electrical heating or steam . Meanwhile, the two pots equip with mixing system. The mixing system is dispersing disk with speed of 1400 rpm. After preparing (feeding, heating, mixing), the raw materials in these two pots can be absorbed into the main pot (emulsifying pot) by the power of vacuum through pipeline.
Technology Parameter
NAME | ZJR-30 | ZJR-50 | |
Emulsifying pot | Design Volume(L) | 30 | 50 |
Capacity(L) | 25 | 40 | |
Scraper Stirring Power(kw) | 0.75 | 0.75 | |
Scraper Stirring Speed(rpm) | 0-86 | 0-86 | |
Homogenizer power(kw) | 1.5 | 1.5 | |
Electrical heating power(kw) | 2 | 4 | |
Homogenizer speed (rpm) | 2800 | 2800 | |
Design Volume(L) | 25 | 38 | |
Capacity(L) | 20 | 30 | |
power(kw) | 0.55 | 0.55 | |
speed(rpm) | 1400 | 1400 | |
Electrical heating power(kw) | 2 | 2 | |
Design Volume (L) | 17.5 | 25 | |
Capacity (L) | 14 | 20 | |
power (kw) | 0.55 | 0.55 | |
speed (rpm) | 1400 | 1400 | |
Electrical heating power (kw) | 2 | 2 | |
Dimension | Emulsifying Length*Width*Height | 1400mm*600mm*(1900-2400)mm | 1400mm*600*(1950-2500)mm |
Water Pot and Oil Pot Length*Width*Height | 880mm*510mm*1050mm | 950mm*550mm*1100mm |
Detailed Images
Packing & Shipping
Packaging:
packing by wooden case usually, we also do other packaging as per customer's requirement.
Shipping:
European Countries: 22-28 days
United States: East --13-16 days, West--21-28 days
Brazil: 30-40 days
Russia: 36 days
Asia Countries: 3-5days
Our Company
About us, click the following to know more...
ღ About YK >
ღ R&D >
ღ Our Customers >
ღ Our Factory >
ღ Our Service >
ღ Our Suppliers >
ღ Honor & Certificates >
ღ Company TIMELINE >
FAQ
1. Why your machine similar with other supplier?
We are an overseas-funded enterprise. We are manufacturer and had been in this industry for more than 17 years, with more than 9 years export experience. We design machines by ourselves with advanced technology. Appearance just a part of machine, Service and quality is more important than it.
2. I'm new in our industry, but I'm planning to set up a factory, What can I do?
We can suggest customer the most suitable machine according to their formula, Raw material. Manufacturing- Installation- Training- Maintenance- Technical Support. We can introduce you supplier of raw material, bottles, labels etc. We could take you to our customer's factory to learn how they produce. We could customize machines according to your real need, We could send our engineer to your factory to install machines and train your worker of Operation and maintenance. Any more requests. Just let us know.
3. The machine is suitable for the production of?
We could offer various kinds of machines and whole production line.
(1) Cream, paste Products
In cosmetic industry: face cream, body cream, washing cream,vaseline etc
In food industry industry: sauce, ketchup, tomato paste, mayonnaise, mustard, chocolate etc
In chemical industry:welding paste,ink, paint,pigment etc.
Production line for them: RO water treatment- vacuum emulsifying machine- storage tanks- filling machine-capping machine- labeling machine- conveyor belt- inkjet printer- sealing machine-shrinking machine etc
(2) Liquid products
shampoo, lotion, liquid soap, detergent, juice, solution, etc.
Production line for them: RO water treatment - liquid wash mixer- - storage tanks- filling machine-capping machine- labeling machine- conveyor belt- inkjet printer- sealing machine-shrinking machine etc
(3) Make-up products:
Lipstick, lip gloss, nail polish, marscara etc
Machines for them: homogenizer mixer, colliod mill, lipstick filling machine, frezzing machine etc
(4) Adhesive products:
Instant glue, AB glue, silica gel, anaerobic adhesive,silicon, sealing etc.
Machines for them: double planet mixer, ribbon blender, tube filling and sealing machine, hydraulic distributing machine, cartridge filling machine, etc.
Strawberry Jam Making Line Machines
