Chinese JiLong KL 300T Fusion Splicer / Splicing Machine
- Category: >>>
- Supplier: Beijing W&f Technology Co. Ltd.
Share on (1600185498340):
Product Overview
Description
Chinese factory KL-300T Fusion Splicer / Splicing Machine
-Core to core alignment by PAS technology ( PAS:Profile Alignment System)
-Digital fusion splicer with automatic focus function
-Fiber core can be display clearly
-Single X or Y view and X & Y view simultaneously
-Auto detect cleaved endface fault
-Display fiber cleaved and offset angle
-Display core and clad offset
-5.6 inch TFT color LCD monitor with clear digital image display
-USB & VGA interface
-Software upgrade via USB interface
1.5.6 inch TFT color LCD monitor
2.Electrode life 2500
3.store 4000 results
4.USB & VGA interface
5.splicing machine
Model | KL-300T |
Applicable fibers | SM (ITU-T G.652), MM (ITU-T G.651), DS (ITU-T G.653), NZDS (ITU-T G.655) |
Fiber cleaved length | 8~16mm(Coating diameter:250µm) 16mm(Coating diameter: 250 ~ 1000µm) |
Fiber diameter | Cladding diameter:80 ~150µm Coating diameter:100~ 1000μm |
Fiber Count | Single |
Fiber aligning method | Core or clad aligning |
Image processing method | Digital |
Actual average splice loss | 0.02dB (SM), 0.01dB (MM), 0.04dB (DS), 0.04dB( NZDS) |
Splicing time | Typical 9 sec,with standard SM fiber |
Splicing mode | 53(templet), 40(user) |
Splice loss estimate | More accurate |
Return loss | up to 60dB |
Storage of splice result | 4000 results,20 parameter per result |
Fiber display and magnification | 300X(X or Y view),150X(X and Y view) |
Tube heating time | Typical 30 sec |
Tube heating mode | 9(templet), 24(user) |
Tube heating temperature | Can be adjusted |
Applicable Protection sleeve length | 60mm, 40mm and a series of micro sleeves |
Tension test | 2N |
Electrode life | 2500 |
No.of splice/heating with battery | Typical 150 cycles (splice/tube heat) with inner Li-battery |
Display screen | 5.6 TFT inch color LCD monitor |
Image change over | The fiber image is turned upside down |
Terminals | USB 1.1 and VGA |
Operating condition | 0 ~ 5000m above sea level, 0 ~ 95%RH and -10~50, respectively, Max. wind velocity of 15m/s |
Power supply | AC 100-240V with AC adapter; inner Li-battery(6600mAH) |
Dimensions | 150mm(L) x150mm (W) x150mm (H) |
Weight | 2.7 Kg excluding battery,3.2 Kg including battery |
Model | KL-300 | KL-300T | KL-280 |
Splicing mode | Auto \\Calibrate Normal \\Special | Auto \\Calibrate Normal \\Special | Auto |
Fiber cleaved angle threshold set | 0.1 - 10.0 ° 0.1°step | 0.1 - 10.0 ° 0.1°step | 0.5 - 8°, 0.5°step |
Display fiber cleaved angle | o | o | - |
Display fiber offset angle | o | o | - |
Auto focusing | o | - | - |
Auto aligning | o | o | o |
Auto detect cleaved endface fault | o | o | - |
Display battery voltage | o | o | - |
Taper Splice | o | o | - |
Sleep | o | o | - |
Auto Shut down | o | o | - |
Software upgrade | o | o | - |
oAvailable -:Unavailable | |||
