Good Quality Factory Directly UV Roller Liquid Coater for Sale
- Category: Coating Machines >>>
- Supplier: Hefei,Kana,Photoelectric,Technology,Co.,Ltd.
Share on:
Product Overview
Description
We can send you coating samples and you can also send us samples for coating test .then check the coating quality.
YOU CAN DOWNLOAD OUR TEST REPORT BY BELOW LINK
https://drive.google.com/drive/folders/1RxkAYGQeX6t-OkrCDNMiC2ykQulrE2U5?usp=sharing
Inkjet printing ADS without coating
KANA UV curable coating
Cold laminating film
Features | Cold roll laminator | IR drying coater | KANA LED UV curing roll coater |
Cost | During production, due to the various sizes of the substrate, Cold laminating film requires large stock volume and has a scrap rate at over 15%. | Infrared radiation dry water-based wet coatings by solvent evaporation which shrinks the initial coating application by more than 50%. The limited length of heating conveyor lower the yield rates to 1-2 m/minute. It is not applicable on heat sensitive substrate. | KANA UV curable coatings have 99.5% solid content of phenolic epoxy resin with additives such as defoamer, leveling agent, photoinitiator and a very little solvents. it costs only 5 to 8g per square meter to apply coatings on various format substrate which can reduce scrap to 2% and increase yield rates to 5-8 m/minute and even 15 m/minute at ultimate load. |
Ductility | The poor ductility of the cold laminating film leads to inconvenience and difficulty in application. | Good ductility leads to easy application | Good ductility leads to easy application |
Quality | The film may easily peel off above +40℃. The Film will easily break below -5℃. Curling, shrinkage, breakage, bubbles and wrinkles happen easily after a short period of time. | If Using A 2kg weight to scratch the coating back and forth at a uniform speed, and the surface coating falls off within 100 times of scratching test. Waterproof quality of IR drying coating is worse than that of UV curable coating. | Excellent adhesion: the coating will not fall off when pulled by 3M tape. Brilliant quality: SGS aging test guarantee no quality change within 1.5 years of outdoor exposure under sunlight and rain and within 48 hours between -20℃ to +68℃. KANA UV curable coating can resist 2000 times of scratching test and 20 times of rubbing with alcohol. |
Color Consistency | PVC laminating film application will darken printing colors due to lower transmittance | the coating surface brightness is among 50°-60°. and it will become darker under high temperature. | KANA UV curable coating has better color consistency due to the higher transmittance. the coating surface brightness can reach 90° -92°. |
Smell | Heavy odor: the odor is difficult to dissipate in a confined space. | Solvent evaporation creates unpleasant smell of ammonia plus environmental pollutants | Only a little smell of epoxy resin. 0.5% solvents solves the problem of volatility and irritation. |
Environmental Friendliness | White Pollution: The PVC laminating film incineration will generate air pollution; PVC takes more than 30 years to decompose. PVC landfill will cause water and soil pollution. | Envrionmentally friendly with no VOCs | Envrionmentally friendly with no VOCs Test report as shown in below pictures |
Human Hazards | Above 65℃, PVC cold laminating film will produce harmful substances and gases such as lead, tin, chlorine, and cause health hazards to humans and animals. | No human hazards | No human hazards Test report as shown in below pictures |
Company Profile
Hefei Kana Photoelectric Technology Co., Ltd. was newly established in April 2020 and is located in Hefei National High-tech Development Zone. The KANA team started focusing on surface coating technology in 2006, and its product development has obtained a number of national authorized patent certificates. Hefei Kana is committed to the R&D, production and marketing of LED cold light source energy-saving coating equipment and surface environmental protection coating materials, and strives to replace all kinds of PVC cold-laminated film protection.
Certifications
Our Advantages
1. Exclusive patent advantage:
Hefei Kana Optoelectronics Technology Co., Ltd. began to focus on surface coating technology in 2006. Its inkjet printing coating series products are in the leading position in the industry, and product development has obtained a number of national authorized patent certificates.
2. Professional production advantages:
Hefei Kana Optoelectronics Technology Co., Ltd. is committed to the R&D, production, promotion and sales of LED cold light source energy-saving coating equipment and surface environmental protection coating materials. It is a professional inkjet coating supplier.
3. Market advantage:
Hefei Kana Optoelectronics Technology Co., Ltd. provides services in the public transportation fields of Beijing Bus, Hangzhou Bus, Nanjing Bus, Shanghai Bus, Kunming Bus and other cities in Mainland China. Cooperate with urban rail transit such as Hangzhou Metro, Guangzhou Metro, Ningbo Metro and Beijing Metro. Directly or indirectly provide inkjet printing coating application services for JCDecaux Media, Yashiwei Media, White Horse Company, CBS and other companies.
4. Product advantages:
KANA coating machine adopts LED cold-light energy-saving curing system, which cures immediately after opening, no high temperature is generated without preheating, and the life of LED light source can reach 15,000 hours. After being processed by the coating machine, the inkjet product can still be used at a high temperature of 68°C and a low temperature of -20°C. The screen is scratch-resistant and anti-aging, without shrinkage, curling, bubbles and wrinkles, and increases the finished product. The weather resistance.
5. Environmental advantages:
The liquid coating can well cover the chemical odors emitted by inkjet inks and adhesive-based adhesives; prevent polyvinyl chloride products from causing secondary harm to the environment, comply with the state’s "plastic limit order" policy, and strive to replace all Like PVC cold laminating film protection.
6. Price advantage:
The coating liquid can be recycled without being cured by the light source, and the loss is low; the substrate has no wide size and specification restrictions, which can reduce the stocking quantity and cost.
7. Quality assurance:
Purchasing high-quality brand materials for the core components of the product not only ensures the stability of product quality, but also reduces the product maintenance rate.
8. After-sale guarantee:
After-sales maintenance response is fast, 24 hours online technical support.
Exhibition
Production Process
Packaging & shipping
FAQ
1. Are you a manufacturer or a trading company?
We are a professional coating machine manufacturer with our own design team and factory, with mature technical experience, and can guarantee product quality and best price.
2. How to install and use the machine?
Once you have ordered the equipment from us, we will send you an English version of the operation video via email. You just need to connect the power cable and start using it. If necessary, we can also video guide you to operate the machine.
3. What price can I get?
We usually quote within 24 hours after receiving your inquiry. If you are in a hurry to ask for the price, please let us know in the mail so that we can respond to your inquiry first.
4. Do you inspect finished products?
Yes, every step of production and finished products must pass QC inspection before shipment.
5. What is the lead time for mass production?
The lead time for large quantities depends on the quantity of the order and the season you placed the order. If you need it urgently, we will make a special arrangement for you.
