Tobee Effluent Handling
$12,600
Petrol pump
- Category: >>>
- Supplier: Shanghai Cowell Machinery Co. Ltd.Shanghai Ltd.
Share on (1600194237733):
Product Overview
Description
YB-65 stainless steel rotary vane pump
Main Features
YB series Self-priming rotary vane pump with internal by-passvalve.The pumps use a rotor with sliding vanes
to draw the liquid. Thematerial of construction is nodular iron with sliding vanes built in aspecial self lubricating
material. Due to its efficiency, the pumpscan handle viscous and also volatile liquids and require less horsepower than other equivalent pumps. The pumps arecapable of higher flow-rates at lower number ofrevolutions than other designs.
Advantage
•Durable pumps for fast and quiet operation.
•Sliding vane design provides sustainedperformanceand trouble freeoperation, high reliability.
•Adjustable relief valve protects pump from excessive pressure.
•T-type strainers are available to protect pumpingsystem fromdamage caused by welding slag and other matter in the piping andtanks.
Maximum Operating Limit | |||||||||||||
Model | Nominal Flowrate | Rated Speed | Viscosity | Differential Pressure | Working Pressure | Temperature | Power | ||||||
GPM | LPM | RPM | SSU | Cp | PSI | Bar | PSI | Bar | 0F | °C | HP | KW | |
YB-50 | 80 | 300 | 640 | 20,000 | 4,250 | 125 | 8.6 | 175 | 12.1 | 300 | 149 | 3 | 2.2 |
YB-65 | 157 | 594 | 640 | 20,000 | 4,250 | 125 | 8.6 | 175 | 12.1 | 300 | 149 | 5 | 4 |
YB-80 | 270 | 1,022 | 640 | 20,000 | 4,250 | 125 | 8.6 | 175 | 12.1 | 300 | 149 | 10 | 7.5 |
YB-100 | 505 | 1900 | 500 | 20,000 | 4,250 | 125 | 8.6 | 175 | 12.1 | 300 | 149 | 25 | 18.5 |
Application
•Fuel oil delivery truck
• Fleet refueling
• Lube oil
• Aviation refuelers
• Transport of Petro Chemicals, gasoline, biofuels, solvents and many more.
Industries:
Automotive; Adhesives; Agriculture; Asphalt ; Aviation fueling ; Animal feeds; Beverage; Cosmetics ;Chemical processing; Concrete Add mixtures; Dairy; Liquid fertilizers; Food processing ; Fuel oil delivery; General industrial; Hydrocarbon processing; Liquefied gases; Lube oils; Marine; Paint and varnish; Petroleum marketing; Petroleum production ; Pharmaceutical; Printing ink; Pulp &paper;Refining commercial Solvents; Recycling Railroad ; Textile.
Packaging & Shipping
YB-50
Without Motor
Packing size(Cm): 44cm*35cm*35cm Net Weight:31KG Gross Weight:34KG
With Motor.V-Belt Driven
Packing size(Cm): 76cm*51cm*55cm Net Weight:86KG Gross Weight:118KG
Outer Packing:1pc/Wooden Case
Every Cowell product is strongly packed by wooden case with metal screw fixation .
Company Information
Shanghai Cowell Machinery Co., Ltd. (Cowell) is a family group company. We are a professional manufacturer of Fueling equipments since 1980's.
Registered in Shanghai, and managed by a professional team, Cowell delivers quality, efficiency, and expertise to our clients worldwide, being dedicated to providing the below full line products:
1) Fuel and LPG dispenser & its components – fuel dispensers, flow meters, fuel pumps, nozzles, separators, manometers, solenoid valves, differential valves, hoses and other related products
2) Mechanical PD Flow Meters & Pumps - positive displacement flow meters and pumps, loading and unloading meters & pumps, Electric Transfer Pump Units, etc.
3) Additional, tank truck parts & digital flow meters.
Cowell factory has Numberical Control Machine Center, Numberical Lathe Machine, Meter Testing Tables, Pump Testing Tables etc. advanced inspecting & testing machines, 3D measurement system.
We have more than 200 employee and 10 senior technical engineers.
Our products are durable, reliable and economical and have obtained ISO9001 certificate, certain products have gained the ATEX CE certificate & UL certificate. The products are exported to USA, Europe, Middle East, South East Asia and Africa etc.
"Cooperation for mutual benefit based on sincerity and credit" is our philosophy. It is our everlasting pursuit to provide our customers with high quality products at competitive prices and efficient customer services.
 | ||
| Warranty: the product is guaranteed for 12 months from the date of delivery under normal condition. | Customers will enjoy free repair services for failures found within the warranty due to manufacturing quality; | We provide paid repair services for products damages not arising from manufacturing quality issues or not within the scope of warranty. |
