2021 news 5000W 6000W 8000W power Inverter generator single phase on grid inverter
- Category: >>>
- Supplier: Shenzhen Hopwin Innovation Technology Co. Ltd
Share on (1600194680296):
Product Overview
Description
Product Description
Items | hopeSun 5KTL | hopeSun 6KTL | hopeSun 8KTL | |||
DC Input | ||||||
Max. PV input voltage | 550Vdc | |||||
MPPT voltage range | 90Vdc ~ 500Vdc | |||||
Max. input current each MPPT | 13A | 26A/13A | ||||
No.of DC Input per MPPT | 2 | 3 | ||||
No. of MPPTs | 2 | |||||
AC Output | ||||||
Rated AC output power | 5kW | 6kW | 8kW | |||
Max. output power | 5.5kW | 6.6kW | 8kW | |||
Rated AC output voltage | 220/230Vac(Single phase) | |||||
Operating voltage range | 176V ~ 276V | |||||
Max. output current | 25A | 30A | 34.8A | |||
Rated grid frequency | 50/60Hz | |||||
Power factor | 0.8 (leading) ~ 0.8 (lagging) | |||||
THD | <3% | |||||
System parameters | ||||||
Max. efficiency | 98.47% | 98.55% | 98.59% | |||
European efficiency | 98.00% | |||||
Protection Level | IP65 | |||||
Operating Temperature Range | -40℃ ~ +60℃ | |||||
Night Power Consumption | <1W | |||||
Cooling System | Natural Cooling | |||||
AC/DC SPD | Support | |||||
Insulation Impedance Detection | Support | |||||
Residual Leakage Current Detection | Support | |||||
PV String Fault Detection | Support | |||||
Output Over current Protection | Support | |||||
Topology Structure | Non-Transformer | |||||
Operating Altitude | 4000m (derating above 3000m ) | |||||
Display | LED Indicator + APP | |||||
Communication | RS485/WiFi(Optional)/GPRS(Optional) | RS485/WiFi (optional)/GPRS (optional) | ||||
Dimensions (W*H*D) | 325*380*177mm | |||||
Weight | 15.5kg | 16.5kg | 17.2kg | |||
