WC67K-100t/3200 Hydraulic Servo CNC Press Brake Stainless Metal Steel Plate Bending Machine with TP10S
- Category: Machine Tool Equipment >>>
- Supplier: Anhui,Harting,Machinery,Technology,Co.,Ltd.
Share on:
Product Overview
Description
WC67K-100t/3200 Hydraulic Servo CNC Press Brake Stainless Metal Steel Plate Bending Machine with TP10S
A press brake is a machine tool for bending sheet and plate material, most commonly sheet metal. It forms predetermined bends by
clamping the workpiece between a matching punch and die.
clamping the workpiece between a matching punch and die.
the stroke length, the distance between the frame uprights or side housings, back gauge distance, and work height.
Product Description
Specification
Type | Nominal force(KN) | Bending length (mm) | Distance between Housings (mm) | Throat Depth (mm) | Back-GaugeRange(mm) | Ram Strokes (mm) | Main Power (kw) | Max Open (mm) |
WC67K-30T1600 | 300 | 1600 | 1200 | 180 | 20-400 | 80 | 3 | 250 |
WC67K-40T1600 | 300 | 2000 | 1200 | 220 | 20-500 | 100 | 5.5 | 320 |
WC67K-40T2500 | 400 | 2500 | 1800 | 220 | 20-500 | 100 | 5.5 | 320 |
WC67K-63T2500 | 630 | 2500 | 2000 | 220 | 20-600 | 100 | 5.5 | 370 |
WC67K-63T3200 | 630 | 3200 | 2500 | 260 | 20-500 | 100 | 5.5 | 370 |
WC67K-80T2500 | 800 | 2500 | 2000 | 260 | 20-600 | 120 | 7.5 | 380 |
WC67K-80T3200 | 800 | 3200 | 2500 | 320 | 20-600 | 120 | 7.5 | 380 |
WC67K-80T4000 | 800 | 4000 | 3100 | 320 | 20-600 | 120 | 7.5 | 380 |
WC67K-100T3200 | 1000 | 3200 | 2660 | 320 | 20-600 | 120 | 7.5 | 380 |
WC67K-100T4000 | 1000 | 4000 | 3060 | 320 | 20-600 | 120 | 7.5 | 380 |
WC67K-125T3200 | 1250 | 3200 | 2700 | 320 | 20-600 | 140 | 11 | 380 |
WC67K-125T4000 | 1250 | 4000 | 3500 | 400 | 20-600 | 140 | 11 | 380 |
WC67K-160T3200 | 1600 | 3200 | 2700 | 400 | 20-600 | 140 | 11 | 470 |
WC67K-160T4000 | 1600 | 4000 | 3500 | 400 | 20-600 | 140 | 11 | 470 |
WC67K-200T3200 | 2000 | 3200 | 2700 | 400 | 20-600 | 180 | 15 | 480 |
Main Features:
1.Totally EU streamlined design,Monoblock by welding robots & aparatus and stress relief process by Annealing treatment.
2.All machines are designed using SOLID WORKS 3D programming and made with enhanced ST44-1 quality steel with the latest
technology.
3. MB8 Series are among the highest rated machines which will help you increase your productivity and keep costs at minimum
levelwith its user friendly NC controller and low cost hydraulic maintenance.
4. High quality and repetitive bending is obtained by using synchronized cylinders and valves.
5. Automatic axis referencing and calibrating when machine is turned on.
6. Rigid upper beam runs on 8-point bearings with bending precision of 0.01 mm
7. Well-known top and bottom tool brands are long lasting stiffened and provide precise bending.Silent high pressure pump.
1.Totally EU streamlined design,Monoblock by welding robots & aparatus and stress relief process by Annealing treatment.
2.All machines are designed using SOLID WORKS 3D programming and made with enhanced ST44-1 quality steel with the latest
technology.
3. MB8 Series are among the highest rated machines which will help you increase your productivity and keep costs at minimum
levelwith its user friendly NC controller and low cost hydraulic maintenance.
4. High quality and repetitive bending is obtained by using synchronized cylinders and valves.
5. Automatic axis referencing and calibrating when machine is turned on.
6. Rigid upper beam runs on 8-point bearings with bending precision of 0.01 mm
7. Well-known top and bottom tool brands are long lasting stiffened and provide precise bending.Silent high pressure pump.
