Product Overview
Description
Product Description
* Industry-leading MainBoard
With MaxwellTM 6 technology, the Integrated Pacific Crest BD970 provides assurance of long-term future-proofing and trouble-free operation. 220 Channels for multi constellation GNSS support.
* Multi-constellation
Not only the superior positioning performance in GPS+GLONASS Satellite system, RUIDE R90T also provides COMPASS compatibility since 2013.
* Advantage of Positioning with COMPASS SystemSatellite availability, tracking time availability and signal acquiring speed are greatly
* Cable-free Operation by Dual BluetoothIntegrated dual bluetooth technology enables the receiver transfer data with controller and your mobile device at the same time.
e Full Flexibility of Data Link
Integrated GSM/GPRS module enables seamless realtime connection with CORS networks. Combining RUIDE exclusive UHF radio technology, R90T can freely switch between GSM/GPRS, Internal or External Radio modes.
* Durability andWaterproof
The ABS+PC material housing provides the maximum ruggedness for the compact and lightweight receiver body. With the IP65 environmental rating, RUIDE R90T can withstand severest condition.
Integrated GSM/GPRS module enables seamless realtime connection with CORS networks. Combining RUIDE exclusive UHF radio technology, R90T can freely switch between GSM/GPRS, Internal or External Radio modes.
* Durability andWaterproof
The ABS+PC material housing provides the maximum ruggedness for the compact and lightweight receiver body. With the IP65 environmental rating, RUIDE R90T can withstand severest condition.
* Complete GNSSSoftware
Full functionality and user-friendliness as well as fully customizable, with RUIDE GNSS Software the data can be downloaded,post-processed and prepared for final processing or direct delivery to clients.
RUIDE high-speed half-duplex GDL20 Data Radio is a powerful and compact 450-470 MHz radio (as default) designed for
* RUIDE GNSS Surveying
With its high power output of 25w, the GDL20 has extremely long range for 15-20km (optimal environment condition) and 9600 bps over-the-air baud rates. Noise immunity is also significantly enhanced via GDL20 radio's forward error correction (FEC).
SMT Assembly Technology(th e high integrated and rugged construction withstands harsh job site conditions.
With its high power output of 25w, the GDL20 has extremely long range for 15-20km (optimal environment condition) and 9600 bps over-the-air baud rates. Noise immunity is also significantly enhanced via GDL20 radio's forward error correction (FEC).
SMT Assembly Technology(th e high integrated and rugged construction withstands harsh job site conditions.
Specification
Survering Performance | ||
Channel | 220 Channels | |
Signal Tracking | BDS B1, B2, B3 | |
GPS L1C/A, L1C, L2C, L2E, L5 | ||
GLONASS L1C/A, L1P, L2C/A, L2P, L3 | ||
SBAS L1C/A, L5(Just for the satellites supporting L5) | ||
Galileo GOIVE-A, GOIVE-B, E1, E5A, E5B | ||
GNSS features | Positioning output rate: 1Hz~50Hz | |
Initialization time: <10s | ||
Initialization reliability: >99.99% | ||
Positioning Precision | ||
Code differential GNSS Positioning | Horization : ± 0.25m + 1ppm | |
Vertical: ± 0.5m + 1ppm | ||
SBAS positioning accuracy: typically<5m 3DRMS | ||
Static GNSS Surveying | Horization : ± 2.5 mm + 0.5 ppm | |
Vertical: ± 5 mm + 0.5 ppm | ||
Real-Time Kinematic Surveying | Horization: ± 8 mm + 1 ppm | |
Vertical: ± 15 mm + 1 ppm | ||
Network RTK | Horization: ± 8 mm + 0.5 ppm | |
Vertical: ± 15 mm + 0.5 ppm | ||
RTK initialization time | 2~8s | |
User Interaction | ||
Buttons | Single button operation | |
Indicators | Three LED indicators lights | |
Secondary development | Providing secondary development package | |
Hardware performance | ||
Dimension | 134×134×118 (mm) | |
Weight | 1kg(including installed battery) | |
Material | Magnesium aluminum alloy shell | |
Operating | 45℃~+60℃ | |
Storage | 55℃~+85℃ | |
Humidity | 100% Non-condensing | |
Waterproof/Dustproof | IP67 standard,protected from long time immersion to depth of 1m | |
IP67 standard,fully protected against blowing dust | ||
Shock and Vibration | Withstand 3 meters pole drop onto the cement ground naturally | |
Power Supply | 9-25V DC, overvoltage protection | |
Battery | Rechargeable,removable Lithium-ion battery,7.4V; standard four batteries | |
power package(optional) | ||
Battery Life | Single battery: > 7h(static mode) | |
> 5h(internal UHF base mode) | ||
> 6h(rover mode) | ||
Communications and Data Storage | ||
I/O Port | 5PIN LEMO external power port + RS232 | |
7PIN external USB (OTG) + Ethernet | ||
1 radio antenna interface, SIM card solt | ||
Wireless Modem | Built-in radio, 2W | |
Raido and internet repater switchable | ||
Frequency range | 410-470MHZ | |
Communication protocol | Trim Talk450s,TrimMark3,PCC EOT,SOUTH | |
Cellular Mobile Network | WCDMA/CDMA2000/TDD-LTE/FDD-LTE 4G network modem, downward | |
compatible with 3G GPRS/EDGE | ||
Double Module Bluetooth | BLEBluetooth 4.0 standard,support for android,ios cellphone connection | |
Bluetooth 2.1+EDR standard | ||
NFC Communication (Optional) | Realizing close range(shorter than 10cm)automatic pair between receiver and | |
controller(controller equipped NFC wireless communication module needed) | ||
External Devices | Optional external GPRS/EDGE dual-mode communication module, switchable; | |
allow to connect external WLAN card | ||
WIFI | ||
Standard | 802.11 b/g standard | |
WIFI Hotspot | The WIFI hotspot allows any mobile terminal to connect and access to the | |
internal webserver for the control and moditor receiver | ||
WIFI data link | To work as the datalink that receiver is able to broadcast and receive | |
differential data via WIFI | ||
Data Storage/Transmission | ||
Data Storage | 8GB SSD internal storage | |
Support external USB storage and automatical cycle storage | ||
Changeable record interval, up to 50Hz raw data download | ||
Data Transmission | USB data transmission, supporting FTP/HTTP data download | |
Data Format | Differential data format: CMR+, CMRx, RTCM2.1, RTCM2.3, RTCM3.0, | |
RTCM3.1,RTCM3.2 | ||
GPS output data format : NMEA 0183, PJK plane coordinates, | ||
Binary code, Trimble GSOF | ||
Network model support: VRS, FKP, MAC, fully support NTRIP protcol | ||
Inertial sensing system | ||
Tilt Survey | Built-in tilt compensator, correcting coordinates automatically according to the | |
tilt direction and angle of the centering rod | ||
Electronic bubble | Controller software display electronic bubble, | |
checking leveling status of the centering rod real time | ||
Thermometer | Bulit-in themomter sensors, adopting intelligent temperature control technology | |
which can mornitor and adjust the temperature of receiver in real time | ||
