1. General Description

OEM-M133T20316B is an Active Matrix Electrophoretic Display (AMEPD),
with interface and a reference system
design. The 13.3” active area contains 960×680 pixels,
and has 1-bit B/W/R full display capabilities. An integrated
circuit contains gate buffer, source buffer, interface, timing control logic, oscillator, DC-DC. SRAM.LUT, VCOM and
border are supplied with each panel.

2. Features
 960×680 pixels display
 High contrast
 High reflectance
 Ultra wide viewing angle
 Ultra low power consumption
 Pure reflective mode
 Bi-stable display
 Commercial temperature range
 Landscape, portrait modes
 Hard-coat antiglare display surface
 Ultra Low current deep sleep mode
 On chip display RAM
 Low voltage detect for supply voltage
 High voltage ready detect for driving voltage
 Internal temperature sensor
 10-byte OTP space for module identification
 Waveform stored in On-chip OTP
 Serial peripheral interface available
 On-chip oscillator
 On-chip booster and regulator control for generating VCOM, Gate and Source driving voltage
 I2C signal master interface to read external temperature sensor/built-in temperature sensor



3. Application
Electronic Shelf Label System
