Industrial 8ft-24 ft giant hvls ceilign fan prix
US $920.00-$1220
Итальянский вентилятор RNM 402A DR, вентилируемый осевой вентилятор высокой емкости и низкого давления, для вентиляционных зданий, электрических и холодильников
- Category: Ventilation Fans >>>
- Supplier: Italsime Macchine Elettriche Srl
Share on (1600201528256):
Product Overview
Description
Product Description
RANGE
Flow rate: 4500 - 8000 [m3/h] | Pressure: 45 - 9 [mmH2O]
APPLICATIONS
For installations requiring large air capacities, in applications for wall, panel or duct fixing. For instance: ventilation of industrial buildings, car parks, stock farms, cooling of electric and refrigerating equipments etc.
CONSTRUCTION
■ RING casing, with wide round shaped nozzle, in epoxy painted steel sheet.
■ Motor side protection grid, manufactured according to UNI EN ISO 12499, and protected against the atmospheric agents.
■ Impeller with high efficiency airfoil blades, in plastic material or in diecast aluminum alloy; hub is in die-cast aluminum alloy. Balancing according to UNI ISO 21940-11. Variable pitch angle in still position.
■ Electric motor, protection IP 55, class F insulated, service S1, construction according to IEC/EEC (UNEL-MEC).
■ Arrangement 4 (impeller directly coupled to motor shaft).
TECHNICAL SPECIFICATIONS
■ Conveyed air: clean, not abrasive.
■ Temperature of conveyed air: -20°C / +50°C.
■ Voltage: Three-phase version (T) 400V-3Ph
■ Frequency: 50Hz
■ Air flow from motor to impeller, position A
Flow rate: 4500 - 8000 [m3/h] | Pressure: 45 - 9 [mmH2O]
APPLICATIONS
For installations requiring large air capacities, in applications for wall, panel or duct fixing. For instance: ventilation of industrial buildings, car parks, stock farms, cooling of electric and refrigerating equipments etc.
CONSTRUCTION
■ RING casing, with wide round shaped nozzle, in epoxy painted steel sheet.
■ Motor side protection grid, manufactured according to UNI EN ISO 12499, and protected against the atmospheric agents.
■ Impeller with high efficiency airfoil blades, in plastic material or in diecast aluminum alloy; hub is in die-cast aluminum alloy. Balancing according to UNI ISO 21940-11. Variable pitch angle in still position.
■ Electric motor, protection IP 55, class F insulated, service S1, construction according to IEC/EEC (UNEL-MEC).
■ Arrangement 4 (impeller directly coupled to motor shaft).
TECHNICAL SPECIFICATIONS
■ Conveyed air: clean, not abrasive.
■ Temperature of conveyed air: -20°C / +50°C.
■ Voltage: Three-phase version (T) 400V-3Ph
■ Frequency: 50Hz
■ Air flow from motor to impeller, position A
Specification
item | value |
Type | Axial Flow Fan |
Applicable Industries | Farms, INDUSTRY |
Customized support | OEM, ODM, OBM |
Electric Current Type | AC |
Mounting | WAL FAN; AIR DUCT; DUCTED SUCTION |
Blade Material | TECHNOPOLYMER |
Place of Origin | Italy |
Brand Name | ITALSIME |
Model Number | RN402A |
Voltage | 230/400 HZ50 |
Certification | ISO 9001 |
Warranty | 1 Year |
After-sales Service Provided | Online support |
color | black/blu |
Packing & Delivery
Type of packaging and shipment of products
Our products are shipped ready for installation, the packaging varies according to the type of transport.
Road and air transport: the product is fixed on pallets and packed with stretch film.
Ship transport: special packaging is made that protects the product from atmospheric agents.
Company Profile
About Us
The ITALSIME company was founded in 1973 as a manufacturer of three-phase, normal and special electric motors.
In 1990 begins the production of the first fans in sheet metal, stainless steel and anti-wear resistance In 2000 the first automated systems for production: welding robots for impellers, In 1998 begins the production of fans according to ATEX (anti-explosion) regulations. laser cutting and automatic machines for the pre-forming of fan cases.
The objective of the ErP Directive 2009/125 / EC is to reduce the energy consumption of the products through eco-design and enviromental sustainability. The structures of the fans are built with folding and reinforcement techniques to give them a light and modern look, but highly resistant, rigid and sturdy.
In 2012 started production of fans according to ErP (Energy-related Product) directives.
Since 2019 the company has been ISO 9001:2015 certified.
The controls on the raw materials, the functional and structural tests of the finished products are performed on ALL fans before leaving the factory. This means a TOTAL quality and reliability of the product.
Troubles, or defects may occur, but they don't leave the factory! The company also uses computerized three-dimensional modeling systems, which reduce the margins of error in the development of prototypes and on standard production. Computer simulations, on the other hand, give certainties in the limits of use of the product and help to predict and prevent the weak points of structures and impellers. The company provides a complete production cycle: from sheet metal cutting, bending, welding, static and dynamic balancing of the impellers up to powder coating in a drying oven and final tests, all perfomed inside Italsime's plant.
Working in the wood working machine area, pellet and waste recovery sector, a production of accessories was also born, such as: Rotary valves, Paper shredder, Refiners and Processing.
Actually ITALSIME exports to more than 20 countries (Europe and extra Europe), either directly or through the network of distributors. The company's aim has always been to find satisfaction in overcoming its limits by listening to requests and learning from its customers.
The ITALSIME organization is mainly aimed at satisfying the needs of: Manufacturers of suction and pneumatic conveying systems in general. Manufacturers of machinery for the wood, glass, metalworking and textile industries. Resellers of technical items in general.
In 1990 begins the production of the first fans in sheet metal, stainless steel and anti-wear resistance In 2000 the first automated systems for production: welding robots for impellers, In 1998 begins the production of fans according to ATEX (anti-explosion) regulations. laser cutting and automatic machines for the pre-forming of fan cases.
The objective of the ErP Directive 2009/125 / EC is to reduce the energy consumption of the products through eco-design and enviromental sustainability. The structures of the fans are built with folding and reinforcement techniques to give them a light and modern look, but highly resistant, rigid and sturdy.
In 2012 started production of fans according to ErP (Energy-related Product) directives.
Since 2019 the company has been ISO 9001:2015 certified.
The controls on the raw materials, the functional and structural tests of the finished products are performed on ALL fans before leaving the factory. This means a TOTAL quality and reliability of the product.
Troubles, or defects may occur, but they don't leave the factory! The company also uses computerized three-dimensional modeling systems, which reduce the margins of error in the development of prototypes and on standard production. Computer simulations, on the other hand, give certainties in the limits of use of the product and help to predict and prevent the weak points of structures and impellers. The company provides a complete production cycle: from sheet metal cutting, bending, welding, static and dynamic balancing of the impellers up to powder coating in a drying oven and final tests, all perfomed inside Italsime's plant.
Working in the wood working machine area, pellet and waste recovery sector, a production of accessories was also born, such as: Rotary valves, Paper shredder, Refiners and Processing.
Actually ITALSIME exports to more than 20 countries (Europe and extra Europe), either directly or through the network of distributors. The company's aim has always been to find satisfaction in overcoming its limits by listening to requests and learning from its customers.
The ITALSIME organization is mainly aimed at satisfying the needs of: Manufacturers of suction and pneumatic conveying systems in general. Manufacturers of machinery for the wood, glass, metalworking and textile industries. Resellers of technical items in general.
FAQ
1. who are we?
We are based in -, Italy, start from 2002,sell to Domestic Market(40.00%),Eastern Europe(40.00%),South Asia(20.00%). There are total about 11-50 people in our office.
2. how can we guarantee quality?
Always a pre-production sample before mass production;
Always final Inspection before shipment;
3.what can you buy from us?
CENTRIFUGAL FANS,AXIAL WENTYLATORS,ROOF EXHAUST FANS,ROTARY WALVES,POLISHERS
4. why should you buy from us not from other suppliers?
Fast production capacity rapid production times both by type and by quantity of productsCustomization possibility to customize the product according to your needs Modularity interchange ability of components according to European standards
5. what services can we provide?
Accepted Delivery Terms: FOB,CIF,EXW；
Accepted Payment Currency:EUR;
Accepted Payment Type: L/C,Credit Card;
Language Spoken:English,German,Russian,Italian
We are based in -, Italy, start from 2002,sell to Domestic Market(40.00%),Eastern Europe(40.00%),South Asia(20.00%). There are total about 11-50 people in our office.
2. how can we guarantee quality?
Always a pre-production sample before mass production;
Always final Inspection before shipment;
3.what can you buy from us?
CENTRIFUGAL FANS,AXIAL WENTYLATORS,ROOF EXHAUST FANS,ROTARY WALVES,POLISHERS
4. why should you buy from us not from other suppliers?
Fast production capacity rapid production times both by type and by quantity of productsCustomization possibility to customize the product according to your needs Modularity interchange ability of components according to European standards
5. what services can we provide?
Accepted Delivery Terms: FOB,CIF,EXW；
Accepted Payment Currency:EUR;
Accepted Payment Type: L/C,Credit Card;
Language Spoken:English,German,Russian,Italian
