2kW low start torque wind turbine with low price

Share on (1600201579482):


Price:$580.00 - $620.00

Quantity:


Product Overview

Description





Introduction

Introduction








Features
*Low start up steed, high wind energy utilization;
*Easy installation, tube or flange connection optional;
*Blades using new art of precision injection molding, matched with optimized aerodynamic shape and structure, which enhance the wind energy utilization and annual output;
*Body of casting aluminum alloy, with 2 bearings swivel, making it survive stronger wind and run more safety;
*Patented permanent magnet ac generator with special stator, effectively reduce torque, well match the wind wheel, generator and ensure the performance of whole system;
*Using MPPT control can adjust the voltage more effectively.







S Style Wind Turbine

S Style Wind Turbine







                                             S Type Wind Turbine













































































































































Model


NE-100S


NE-200S


NE-300S


NE-100S2


NE-200S2


NE-300S2


NE-400S2


Rated Power


100W


200W


300W


100W


200W


300W


400W


Maximum Power


130W


220W


310W


130W


220W


310W


410W


Rated Voltage


12/24V


12/24V


12/24V


12/24V


12/24V


12/24V


24V


Start-up Wind Turbine



2M/S



Rated Wind Speed


10M/S


11.5M/S


13M/S


10M/S


11.5M/S


13M/S


13M/S


Safety Wind Speed


55M/S


55M/S


50M/S


55M/S


55M/S


50M/S


50M/S


Top Net Weight


6KG


6.2KG


6.5KG


5KG


5.2KG


5.6KG


5.8KG


Wheel Diameter


1.2M


1.3M


1.35M


1.2M


1.3M


1.35M


1.4M


Number of Blades


3/5


Blades Material


Nylon fiber


Generator


Three phase permanent magnet ac synchronous generator


Magnet


NdFeb


Generator Case


Casting Aluminum Alloy


Control System


Electromagnet


Speed Regulation


Automatically adjust wind ward direction


Work Temperature


-40~80℃


Design Life


20 years





















M Style Wind Turbine

M Style Wind Turbine







M Type Wind Turbine



















































































































































































Model


NE-300M


NE-400M


NE-400M2


NE-500M2


NE-500M3


NE-600M4


NE-700M4


NE-800M5


NE-1000M5


Rated Power


300W


400W


400W


500W


500W


600W


700W


800W


1000W


Maximum Power


320W


410W


420W


520W


510W


630W


720W


820W


1050W


Rated Voltage


12/24V


12/24V


24V


24/48V


24V


24/48V


24/48V


24/48V


48V


Start-up Wind Turbine


2M/S


2M/S


2.5M/S


2.5M/S


2M/S


2.5M/S


2.5M/S


2.5M/S


2.5M/S


Rated Wind Speed


11M/S


11.5M/S


11M/S


11M/S


11M/S


11M/S


11M/S


12M/S


12.5M/S


Safety Wind Speed


50M/S


50M/S


45M/S


45M/S


45M/S


45M/S


45M/S


40M/S


40M/S


Top Net Weight


9.2KG


9.5KG


14.5KG


15KG


11.5KG


20KG


21KG


29KG


30KG


Wheel Diameter


1.35M


1.55M


1.7M


1.75M


1.75M


1.85M


1.85M


2.2M


2.4M


Number of Blades


3/5


3/5


3/5


3/5


3


3


3


3


3


Blades Material



Nylon fiber



Generator



Three phase permanent magnet ac synchronous generator



Magnet



NdFeb



Generator Case



Casting Aluminum Alloy



Control System



Electromagnet



Speed Regulation



Automatically adjust wind ward direction



Work Temperature



-40~80℃



Design Life



20 years








L Style Wind Turbine

L Style Wind Turbine




L Type Wind Turbine























K Style Wind Turbine

K Style Wind Turbine





















G Style Wind Turbine

G Style Wind Turbine
