8x4 1SUZU GIGA 20Ton Freezer Vehicle Thermo King Fish Seafood Reefer Food Meat Transport Refrigerator Trucks in Saudi Arabia
- Category: >>>
- Supplier: Hubei Hontop Special Vehicle Co. Ltd.
Share on (1600201710775):
Product Overview
Description
Product Description
8x4 QINGLING GIGA Large Capacity Freezer Vehicle 20T Reefer Refrigerator Truck with Thermo King Refrigerator Unit
Refrigerator truck (also called reefer truck,refrigerator wagon,refrigerator van,refrigerated vans,refrigerated truck, refrigerated boxcar,vaccine delivery truck, food refrigerated truck,Medical waste refrigerated truck,freezer vehicle, freezer wagon,temperature controlled truck, refrigerator car, preservation vehicle) is used to carry perishable stuff at special temperatures,such as frozen foods, seafood,fresh fruit and vegetables, vaccine medicine, medical waste and so on.
Refrigeration truck includes truck chassis,insulated heat preservation box body (polyurethane material, fiber glass, color plate,stainless steel plate,etc), refrigeration units, cabin temperature controller and so on. For special required trucks such as meat hook refrigeration truck, there can also add meat hooks,guide rail, aluminium alloy guide, Fixed cargo slot,ventilating slot,2-compartment (one fresh and another frozen box),and so on.
Famous chassis such as ISUZU, Dongfeng, Foton, FAW, JAC, JMC, Sino truk,Shacman,etc.
Refrigeration Truck Insulated box body: "sandwich" type structure Fiberglass+PU+fiberglass (FRP+PU+FRP),All the double surface sandwich polyurethane panel and door are 85-100mm thickness, the Fiber glass plate is for the outer and inner skins;The padding material is polyurethane foam that has super temperature preservation ability with varieties of thickness options.The polyurethane foam density is 45-50kg/m 3. (All is the best material in China and have excellent insulation performance) . The hardware (door frame, hinge, lock, handle) are made of 304 stainless steel, and wrap angle are aluminum alloy.Sandwich panel thickness can be changed according to customers' requirements：60mm, 80mm, and 100mm.
Refrigeration units: famous refrigeration units,Thermo King&Carrier,K series,KAILI,HANXUE,etc.Independent type refrigeration units and dependent type refrigeration units( two types of power driving ways-one is powered by vehicle engine through PTO, the other is driven by a separately carried power unit).
Hontop can supply reefer van trucks wih capacity from 1Ton,2Ton, 3.2Ton, 4Ton, 5Ton,6.3Ton,8Ton, 10Ton,12Ton,14Ton,16Ton,25Ton.
Temperature range from +7°C， +2°C， -10°C， -15°C， -20°C， -25°C.
Our frigerator truck also have side-door,Straight line guide rail,Butt joint guiderail,5-sided ventilation slot,etc.
Refrigerator truck (also called reefer truck,refrigerator wagon,refrigerator van,refrigerated vans,refrigerated truck, refrigerated boxcar,vaccine delivery truck, food refrigerated truck,Medical waste refrigerated truck,freezer vehicle, freezer wagon,temperature controlled truck, refrigerator car, preservation vehicle) is used to carry perishable stuff at special temperatures,such as frozen foods, seafood,fresh fruit and vegetables, vaccine medicine, medical waste and so on.
Refrigeration truck includes truck chassis,insulated heat preservation box body (polyurethane material, fiber glass, color plate,stainless steel plate,etc), refrigeration units, cabin temperature controller and so on. For special required trucks such as meat hook refrigeration truck, there can also add meat hooks,guide rail, aluminium alloy guide, Fixed cargo slot,ventilating slot,2-compartment (one fresh and another frozen box),and so on.
Famous chassis such as ISUZU, Dongfeng, Foton, FAW, JAC, JMC, Sino truk,Shacman,etc.
Refrigeration Truck Insulated box body: "sandwich" type structure Fiberglass+PU+fiberglass (FRP+PU+FRP),All the double surface sandwich polyurethane panel and door are 85-100mm thickness, the Fiber glass plate is for the outer and inner skins;The padding material is polyurethane foam that has super temperature preservation ability with varieties of thickness options.The polyurethane foam density is 45-50kg/m 3. (All is the best material in China and have excellent insulation performance) . The hardware (door frame, hinge, lock, handle) are made of 304 stainless steel, and wrap angle are aluminum alloy.Sandwich panel thickness can be changed according to customers' requirements：60mm, 80mm, and 100mm.
Refrigeration units: famous refrigeration units,Thermo King&Carrier,K series,KAILI,HANXUE,etc.Independent type refrigeration units and dependent type refrigeration units( two types of power driving ways-one is powered by vehicle engine through PTO, the other is driven by a separately carried power unit).
Hontop can supply reefer van trucks wih capacity from 1Ton,2Ton, 3.2Ton, 4Ton, 5Ton,6.3Ton,8Ton, 10Ton,12Ton,14Ton,16Ton,25Ton.
Temperature range from +7°C， +2°C， -10°C， -15°C， -20°C， -25°C.
Our frigerator truck also have side-door,Straight line guide rail,Butt joint guiderail,5-sided ventilation slot,etc.
Specification
item | value | |
Vehicle Name | 8x4 QINGLING GIGA Large Capacity Freezer Vehicle 20T Reefer Refrigerator Truck with Thermo King Refrigerator Unit | |
Chassis brand | ISUZ-U | |
Whole Vehicle Size | 12000×2600×3990MM | |
Cargo Box size | 9550×2420×2370mm | |
GVW | 31000KG | |
Curb weight | 14650kg | |
Cab seat | 2person | |
Air Conditoner | Yes | |
Fuel type | Diesel | |
Engine Model | 6UZ1-TCG50 | |
Engine brand | ISUZU | |
Power | 380HP | |
Emission Standard | Euro 5 | |
Drive Type | 8X4 | |
Transmission | 12-Speed gearbox, Manual | |
Wheelbase(mm) | 1850+4575+1370MM | |
Tyre Specification | 12.00R22.5 | |
Tyre No.(pcs) | 12+1 | |
Max Speed(km/h) | 100 | |
Paint | as your required | |
Superstructure | ||
Temperature | lowest -15℃ | |
Volume | 55m3 | |
Structure | extruded polystyrene board filled in the wall as the heat insulation Stainless steel lock, door and hinge Rear double door | |
Body thickness | 8-10mm | |
Other | Temperature and humidity recorder Adjustment and display of temperature | |
Details Images
Optional Configuration:
Side-door
floor ventilation slot
Middle Fixed-cargo slot
straight line guiderail
USA THERMO KING/CARRIER Refrigeration Unit
SS304 Internal Wall and door
Movable 2-compartment partition
Fixed 2-compartment partition
Packing & Delivery
Ro-Ro,Bulk,All vehicles have been waxed before shipment
