1A~30A equipment 1 Pole plug in hydraulic magnetic miniature black circuit breaker for machine use

Product Overview

Description





HC30R Hydraulic Magnetic Circuit Breaker



Hydraulic Magnetic Circuit Breaker:



1.Application:



Small size,light weight,novel structure andexcellent performance. Connection way: bolt screw

mini circuit breaker: Adopt the advance Hydraulic Magnetic technology



2.MAIN TECHNICAL PARAMERER



Name	Hydraulic Magnetic Circuit Breaker
Pole	1P
Series	HC30R
Voltage	125/250/318/415 Vac;  65/80 Vdc
Rated Current	1-50A
Mounting	Panel Mounted
Operating Temperature	-20ºC to 60ºC
Interrupt Capacity	1,000A





3.HC30R OVER-CURRENT PROTECTION PROPERTY

Current	23±2°C release time(s)
	In	1.35In	1.5In	2In	6In	10In
AC	Non-release	3-70	2-40	1.0-15	0.01-3	0.01-0.5



 RATED PRODUCTS
