GGG50 DIN 3352 F4 ductile iron gate valve with prices soft seal cast iron sluice gate valve
- Category: >>>
- Supplier: Tianjin Lituo Valve Co. Ltd.
Share on (1600210834076):
Product Overview
Description
Product Description
ductile iron gate valve
Cast Iron Resilient Gate Valve Technical Parameters:
Connection Ends | Flange to DIN EN 1092-2:1997 |
Working Pressure | PN10 / PN 16 |
Temperature Range | 0℃-80℃ |
Coating | Fusion Bonded Epoxy Coating in Accordance with ANSI / AWWA C550 |
Cast Iron Gate Valve Optional Materials for Parts:
Parts No. | Parts | Standard Specification | Options |
1 | Body | EN-GJS-450-10 |
|
2 | Resilient Wedge Disc | EN-GJS-450-10+EPDM |
|
3 | Stem | SS420 | SS304,SS316,SS431,AL-Bronze |
4 | Nut | Carbon Steel Zinc Plated | SS304,SS316 |
5 | Bonnet | EN-GJS-450-10 |
|
6 | O-ring | NBR | EPDM |
7 | Gland | EN-GJS-450-10 |
|
8 | Handlewheel | EN-GJS-450-10 | Pressed Steel |
9 | Bolt | Carbon Steel Zinc Plated | SS304,SS316 |
10 | Flat Washer | Carbon Steel Zinc Plated | SS304,SS316 |
11 | Ring Wiper | EPDM | NBR |
12 | O-ring | Carbon Steel Zinc Plated | SS304,SS316 |
13 | Flat Washer | Carbon Steel Zinc Plated | SS304,SS316 |
14 | O-ring | NBR | EPDM |
15 | Thrust Washer | Brass HPb59-1 |
|
16 | Bonnet Gasket | EPDM | NBR |
17 | Wedge Nut | Brass HPb59-1 | Bronze ZASn5-5-5 |
Packaging & Shipping
We have been worked as a valve supplier for many years, so far we have established with many customers from all over the world, such as : Russia, Ukraine, Malaysia, , UAE... . So we have a big experience to work together with you. And we believe in that our quality is good and our price is competitive. Hope we can become your reliable and stable supplier in China.
We have our own factory, so products can be customized according to your request.
