Лидер продаж, настольный лазерный резак, плоттер, лазерный резак с оптоволоконным лазером Raycus MAX, 1000 Вт, 2000 Вт, 3000 Вт
- Category: Laser Cutting Machines >>>
- Supplier: Shandong Raytu Laser Technology Co. Ltd.
Share on (1600211318159):
Product Overview
Description
Hot Sale Model Table Top Laser Cutter plotter de corte laser With Raycus MAX Fiber Laser 1000W 2000W 3000W
Specification
Equipment Specification | ||||||||||
Model | RTC3015H | RTC4015H | RTC6015H | RTC4020H | RTC6020H | |||||
Cutting Area | 3000*1500mm | 4000*1500mm | 6000*1500mm | 4000*2000mm | 6000*2000mm | |||||
Laser source | MAX | MAX | MAX | MAX | MAX | |||||
Max Moving Speed | 100m/min,Acc=1.0G | 100m/min,Acc=1.0G | 100m/min,Acc=1.0G | 100m/min,Acc=1.0G | 100m/min,Acc=1.0G | |||||
Position Accuracy | ±0.03mm | ±0.03mm | ±0.03mm | ±0.03mm | ±0.03mm | |||||
Reposition Accuracy | ±0.02mm | ±0.02mm | ±0.02mm | ±0.02mm | ±0.02mm | |||||
Power | 380V 50/60Hz 50A | 380V 50/60Hz 50A | 380V 50/60Hz 50A | 380V 50/60Hz 50A | 380V 50/60Hz 50A | |||||
Max Loading(KG) | ≤4000 | ≤5000 | ≤5500 | ≤6000 | ≤6000 | |||||
Machine Parts
Fiber Laser
1.Electro-optical conversion efficiency up to 30%.
2. They are excellent beam quality, high energy density, and reliability, a wide modulation frequency;
3. 100,000 hours of lifetime, free maintenance; Low energy consumption, only 20%-30% of the traditional CO2 machine.
2. They are excellent beam quality, high energy density, and reliability, a wide modulation frequency;
3. 100,000 hours of lifetime, free maintenance; Low energy consumption, only 20%-30% of the traditional CO2 machine.
Laser Head
1. Optimized design structure: modularization, easy maintenance, and reduced downtime.
2. Multiple protective lenses: 3 protective lenses, efficient protection of collimating focusing lenses.
3. Durable and durable: 2-way optical water cooling, effectively extending continuous working time.
4. Closed-loop step-by-step automatic focusing: A closed-loop stepper motor is used to effectively avoid losing steps. The focusing speed is 100mm/s, and the repeatability is 1μm.
5. Fast piercing High speed cutting: 16mm low carbon steel, piercing time <6 seconds, cutting speed 0.6m/min.
2. Multiple protective lenses: 3 protective lenses, efficient protection of collimating focusing lenses.
3. Durable and durable: 2-way optical water cooling, effectively extending continuous working time.
4. Closed-loop step-by-step automatic focusing: A closed-loop stepper motor is used to effectively avoid losing steps. The focusing speed is 100mm/s, and the repeatability is 1μm.
5. Fast piercing High speed cutting: 16mm low carbon steel, piercing time <6 seconds, cutting speed 0.6m/min.
High precision machine bed
1. Fiber laser cutting machine lathe bed part completely independent research and development, by the party welding lathe bed base, through the large gantry milling machine.
2. For large machine bed we have many years of experience in processing, each
machine bed will be placed 30 to 45 days after rough machining natural failure, the internal stress release completely again after finishing, ensure the machining accuracy. High strength, stability, ensuring 20 years of use without distortion.
machine bed will be placed 30 to 45 days after rough machining natural failure, the internal stress release completely again after finishing, ensure the machining accuracy. High strength, stability, ensuring 20 years of use without distortion.
Water Chiller
1. Automatically adjust the temperature according to different working environment, no need to change settings parameters. Reduce the temperature of the laser source and the laser head through water circulation, thereby protecting these two main parts.
2. The chiller has functions such as water flow protection and water temperature protection. If the chiller is not opened or the water flow is insufficient, the laser will not be generated when the water temperature is too high, so as to protect the laser.
Servo Motor
Y axis: Double sets Japanese FUJI Servo motors and drivers.
X axis: Japanese FUJI Servo motor and driver Our X Y axis structure increases machine speed and precision and more stable for machine working.
Z axis: Japanese Servo motor and driver.
X axis: Japanese FUJI Servo motor and driver Our X Y axis structure increases machine speed and precision and more stable for machine working.
Z axis: Japanese Servo motor and driver.
Control System
1. Advantech industrial computer, with professional Weihong optical fiber cutting control system, can cut metal plates well. High cutting speed and perfect cutting edge, smooth plane and exquisite texture.
2. Save the metal cutting parameters of various technologies in the computer before leaving the factory.
Application
What is fiber laser cutting machine Application?
Used in sheet metal processing, aviation, aerospace, electronics, electrical appliances, subway parts, automobiles, grain machinery, textile machinery, engineering machinery, precision parts, ships, metallurgical equipment, elevators, household appliances, craft gifts, tool processing, decoration, advertising , metal processing, kitchen processing and other manufacturing and processing industries.
Used in sheet metal processing, aviation, aerospace, electronics, electrical appliances, subway parts, automobiles, grain machinery, textile machinery, engineering machinery, precision parts, ships, metallurgical equipment, elevators, household appliances, craft gifts, tool processing, decoration, advertising , metal processing, kitchen processing and other manufacturing and processing industries.
What materials can laser cutting machines be applied to?
Material Application:Stainless steel, carbon steel, alloy steel, silicon steel, spring steel, aluminum, aluminum alloy, galvanized sheet, galvanized sheet, pickled sheet, copper, silver, gold, titanium and other metal sheet and pipe cutting.
Material Application:Stainless steel, carbon steel, alloy steel, silicon steel, spring steel, aluminum, aluminum alloy, galvanized sheet, galvanized sheet, pickled sheet, copper, silver, gold, titanium and other metal sheet and pipe cutting.
Cutting Parameter
Our Service
① Pre-sale services Before signing a contract, our company provides customers a variety of production technology proposal, technical advice of laser equipment, sample specimens, equipment selection, and price etc. all aspect of consulting and services. We sincerely welcome customers to visit our company and factory, and we provide customers reception staff, food, transportation and other facilities.
② Sale of services Based on the contract, we delivery laser machine to customers place safely within the specified time, We provide Installation and technical training. The training as follows:
1. Training operating instruction of turning on and off machine;
2. Meaning of panel and control parameters;
3. Training parameter selection range;
4. Training control software operation ;
5. Basic maintenance and cleaning of the machine;
6. Dealing with common hardware problem;
7. Noted question in operating ;
8. In addition to, we also provide users technical support related their producing products.
③ After-sale services To provide customers with all aspects of service. We promise:
1. Three year warranty of machine.
2. Customer service will be feedback within 12 hours.
3. We provide machine lifetime maintenance services though warranty expires.
4. Offered a wide range of hardware and software support after the warranty expires, enjoy free upgrades.
Installation and commissioning cost, technician's tickets and all cost mentioned need to be negotiated.
Company Profile
Shandong Raytu Laser Technology Co., Ltd. is a professional R&D, production and sales of laser equipment high-tech enterprises.The company has a group of top laser technology talents, established a covering China, radiation of the global sales system.The company has a standardized intelligent equipment base, committed to fiber cutting machine, intelligent robot research and development, manufacturing and sales.The equipment is widely used in advertising industry, arts and crafts gifts, precision instruments, auto parts, jewelry and other industries.To meet the needs of customers in different industries, and rely on excellent design, excellent and stable performance, won the unanimous recognition of customers at home and abroad. The company regards the quality as the life, takes the technology as the foothold this, we will always adhere to "the quality, the customer is supreme, strictly observes the prestige, serves the society" the purpose, the warm welcome from all walks of life friend comes to the company to visit, the investigation, the guidance. Corporate mission: To be a one-stop procurement platform for laser engraving machine industry.Corporate vision: Made in China, leading the world. Corporate values: integrity, innovation, gratitude, cooperation, efficiency.
FAQ
Q: How do I install this machine?
A: The machine has been installed and debugged before leaving the factory, and can be used directly after receiving it.
Q: How do I operate this machine?Is training necessary?
A:The machine is mainly controlled by software.Simple, not complicated.Before delivery, we will make a simple operation manual and pictures, and provide the software manual.Generally speaking, an operator who is not familiar with the fiber laser marking machine can still operate it well.According to customer requirements, we can send technicians to the customer's factory for machine training, or when the customer needs to come to our factory for machine training.
Q: If there is a problem with the machine, what about the after-sales service?
A: We offer a three-year warranty on the machines.Within the two-year warranty period, if there is any problem with the machine,we will deliver the required parts free of charge.But man-made damage is not covered by our warranty.After the warranty period, we still offer a lifetime service.
A: The machine has been installed and debugged before leaving the factory, and can be used directly after receiving it.
Q: How do I operate this machine?Is training necessary?
A:The machine is mainly controlled by software.Simple, not complicated.Before delivery, we will make a simple operation manual and pictures, and provide the software manual.Generally speaking, an operator who is not familiar with the fiber laser marking machine can still operate it well.According to customer requirements, we can send technicians to the customer's factory for machine training, or when the customer needs to come to our factory for machine training.
Q: If there is a problem with the machine, what about the after-sales service?
A: We offer a three-year warranty on the machines.Within the two-year warranty period, if there is any problem with the machine,we will deliver the required parts free of charge.But man-made damage is not covered by our warranty.After the warranty period, we still offer a lifetime service.
