PO TRY 8 HEADS heat transfer printing sublimation printer for textile with i3200 printhead

Share on:

Price in USD:Details


Product Overview




Polyester printing Heat Transfer Sublimation Printer 8 printheads I3200



Specifications&technical Data
Model numberBC-1908E-HT
PrintheadEPSON I3200
Number of Print heads8
Print resolution/speed1Pass 360*1200DPI 300m²/H
2Pass 360*2400DPI 150m²/H
Print Width1900mm
Ink TypeSublimation Ink
Ink Capacity4*5L
Precision ModeVSD Variable point model
ColorK C M Y
Print Media optionalHeat-Transfer printing Paper
Max Medium Weight80KGS
RIP softwareMaintop 6.0 /  Wasatch / Neostampa (optional)
Computer SystemWin 7 64bit
Computer configuration ReferenceHard disk: 500G / 1T,  ATI  independent video card,  Gigabit network card, 4G or  8G memory,  Intel quad-core i5 or i7 CPU processor.
File formatTIF
Work environmentTemperature: 18 -28℃, Humidity: 40%-60%.
Rolling systemAutomatic Feeding and Collecting roll Paper or Textiles.
Drying systemAutomatic Drying system
Power SupplyAC220V ± 10%. 50/60 ± 1Hz(AC110V ± 10%. Optional)
Advanced FeatureAutomatic cleaning; Automatic Alarming System for Empty Ink Supply;  Automatic flash spray   moisturizing function.
Machine Size L2800mm*W1300mm*H1600mm
Outer Box Size L3350mm*W780*1010mm + L2540mm*W1300mm*H850mm ( two wooden boxes)
Net Weight 435KGS
Gross Weight655KGS




1.Adopt new integrated cleaning moisturizing ink stack.
2.Displacement of Ink cartridge bottom plate, adjustment is more convenient, printing accuracy is higher.
3.3 EPSON 4720/3200/5113 printhead 2pass speed up to 120m2/h.
4.Gigabit network data transmission port to meet the requirements of digital print high-definition picture output stability and transmission speed
5.Adopt imported original parts: THK ultra-quiet rail, Japan NSK Bearings, Germany Igus chain of ink, Lei Sai servo brushless integrated motor.
6.Automatic tension adjustment reel to quickly rewind the print media. Itelligent test paper to prevent paper and paper edge phenomenon.
If there is an accident, the printer automatically pauses to prevent the printhead from being scratched.
