Dongfeng cummins 6CTA8.3 M205 SO20747 6LTAA8.9 M315 SO31024 for main propulsion
Dongfeng cummins 6CTA8.3-M205 SO20747 6LTAA8.9-M315 SO31024 for main propulsion
Dongfeng cummins 6CTA8.3-M205 SO20747 6LTAA8.9-M315 SO31024 for main propulsion
Dongfeng cummins 6CTA8.3-M205 SO20747 6LTAA8.9-M315 SO31024 for main propulsion
Dongfeng cummins 6CTA8.3-M205 SO20747 6LTAA8.9-M315 SO31024 for main propulsion
Dongfeng cummins 6CTA8.3-M205 SO20747 6LTAA8.9-M315 SO31024 for main propulsion

Dongfeng cummins 6CTA8.3 M205 SO20747 6LTAA8.9 M315 SO31024 for main propulsion

Share on (1600212890909):


Price:$15,000.00

Quantity:


Product Overview

Description



Product Description


Shanghai Stone Diesel Engine Co., Ltd supply complete cummins marine engine with gearbox, propeller and shaft. We also have cummins marine engine for generator.
Dongfeng cummins 6BT5.9-M120 SO14002 6BTA5.9-M150 SO14003 for main propulsion
Dongfeng cummins 6CTA8.3-M188 SO21226 6CTA8.3-M220 SO21275 for main propulsion
Dongfeng cummins 6CTA8.3-M205 SO20747 6LTAA8.9-M315 SO31024 for main propulsion
Dongfeng cummins 6BT5.9-M120 6BTA5.9-M150 6CTA8.3-M188 for main propulsion
Dongfeng cummins 6CTA8.3-M205 6CTA8.3-M220 6LTAA8.9-M315 for main propulsion


General data of Cummins 6LTAA8.9-M315 Marine Propulsion Engine
Engine Model
Cummins 6LTAA8.9-M315
Type
6 cylinder in line
Displacement
8.9 L
Bore&Stroke
114×145 mm
Dry Weight
650 KG
Dimension(L*W*H)
Center of gravity from front face of block
427 mm
Center of gravity above crankshaft centerline
163 mm
Technical data of Cummins 6LTAA8.9-M315 Marine Propulsion Engine
Aspiration
Turbocharged and Charge Air Cooled
Fuel System
BOSCH P7100/RQV_K
Coolant liquid capacity-engine only
11.1 litre
Low Idle speed
600-800 RPM
High Idle speed
2430 RPM
Compression ratio
16.6:1
Piston Speed
10.3 m/sec
Firing Order
1-5-3-6-2-4
Performance Date of Cummins 6LTAA8.9-M315 Marine Propulsion Engine
Rated Output/Speed
230KW/315HP/2134RPM
Standby Output/Speed
253KW/346HP/2200RPM
Max torque/speed
1350N.m/1400RPM
Frequency(HZ)
Fuel Consumption/rated speed
64l/hr/1858RPM


6BT5.9-M120 SO14002
AD fuel pump,RSVmechanical speed adjuster.
Rated power:90kW/2200RPM;Max power:100KW/2270RPM
6BTA5.9-M150 SO14003
AD fuel pump,RSVmechanical speed adjuster.
Rated power:110kW/2200RPM;Max power:120KW/2270RPM
6CTA8.3-M188 SO21226
AD fuel pump,RSVmechanical speed adjuster.
Rated power:138kW/2328RPM;Max power:152KW/2400RPM
6CTA8.3-M205 SO20747
AD fuel pump,RSVmechanical speed adjuster.
Rated power:151kW/2328RPM;Max power:166KW/2400RPM
6CTA8.3-M220 SO21275
AD fuel pump,RSVmechanical speed adjuster.
Rated power:164kW/1800RPM;Max power:180KW/1858RPM
6LTAA8.9-M315 SO31024
P7100 pump,RSVmechanical speed adjuster.
Rated power:230kW/2134RPM;Max power:253KW/2200RPM




Packing & Delivery




wooden box
