CUMMINS ENGINE 6CT8.3 GM115 SO20722 SO20782 SO20795 for marine generator
- Category: >>>
- Supplier: Shanghai Stone Diesel Engine Co. Ltd.
Share on (1600213512433):
Product Overview
Description
Product Description
Shanghai Stone Diesel Engine Co., Ltd supply complete cummins marine engine with gearbox, propeller and shaft. We also have cummins marine engine for generator.
Dongfeng cummins 4BTA3.9-GM47 6BT5.9-GM83 6BTA5.9-GM100 for main generator set
Dongfeng cummins 6BTAA5.9-GM115 6CT8.3-GM115 6CTA8.3-GM155 for main generator set
Dongfeng cummins 6BT5.9-GM100 6CT8.3-GM115 6LTAA8.9-GM200 for main generator set
CUMMINS ENGINE 4BTA3.9-GM47 SO11070 SO13280 SO11071 for marine generator
CUMMINS ENGINE 6BT5.9-GM83 SO10938 SO10940 SO10939 for marine generator
CUMMINS ENGINE 6BTA5.9-GM100 SO11104 SO11105 for marine generator
CUMMINS ENGINE 6BTAA5.9-GM115 SO11126 SO11126 for marine generator
CUMMINS ENGINE 6CT8.3-GM115 SO20722 SO20782 SO20795 for marine generator
CUMMINS ENGINE 6CTA8.3-GM155 SO20730 SO20864 SO20783 for marine generator
CUMMINS ENGINE 6CTA8.3-GM155 SO20937 SO20796 SO20938 for marine generator
CUMMINS ENGINE 6CTA8.3-GM155 SO20796 SO20938 SO20938 for marine generator
CUMMINS ENGINE 6LTAA8.9-GM200 SO30763 SO30197 for marine generator
CUMMINS ENGINE 4BTA3.9-GM65 SO10969 SO12314 for marine generator
CUMMINS ENGINE 6BT5.9-GM100 SO10880 SO13781 SO10972 for marine generator
CUMMINS ENGINE 6BTA5.9-GM120 SO11106 SO11120 SO11149 for marine generator
CUMMINS ENGINE 6CT8.3-GM129 SO22188 for marine generator
CUMMINS ENGINE 6BT5.9-GM83 SO10938 SO10940 SO10939 for marine generator
CUMMINS ENGINE 6BTA5.9-GM100 SO11104 SO11105 for marine generator
CUMMINS ENGINE 6BTAA5.9-GM115 SO11126 SO11126 for marine generator
CUMMINS ENGINE 6CT8.3-GM115 SO20722 SO20782 SO20795 for marine generator
CUMMINS ENGINE 6CTA8.3-GM155 SO20730 SO20864 SO20783 for marine generator
CUMMINS ENGINE 6CTA8.3-GM155 SO20937 SO20796 SO20938 for marine generator
CUMMINS ENGINE 6CTA8.3-GM155 SO20796 SO20938 SO20938 for marine generator
CUMMINS ENGINE 6LTAA8.9-GM200 SO30763 SO30197 for marine generator
CUMMINS ENGINE 4BTA3.9-GM65 SO10969 SO12314 for marine generator
CUMMINS ENGINE 6BT5.9-GM100 SO10880 SO13781 SO10972 for marine generator
CUMMINS ENGINE 6BTA5.9-GM120 SO11106 SO11120 SO11149 for marine generator
CUMMINS ENGINE 6CT8.3-GM129 SO22188 for marine generator
General data of Cummins 6CT8.3-GM115 Marine Auxiliary Engine | ||
Engine Model | Cummins 6CT8.3-GM115 | |
Type | 6 cylinder in line | |
Displacement | 8.3 L | |
Bore&Stroke | 114×135 mm | |
Dry Weight | 702 KG | |
Dimension(L*W*H) | ||
Center of gravity from front face of block | 541 mm | |
Center of gravity above crankshaft centerline | 163 mm | |
Technical data of Cummins 6CT8.3-GM115 Marine Auxiliary Engine | ||
Aspiration | Turbocharged & Water-Air Intercooled | |
Fuel System | PB Pump/GAC Governor Regulation 3% | |
Coolant liquid capacity-engine only | 12.3 litre | |
Idle speed | 950-1050 RPM | |
Compression ratio | ||
Piston Speed | m/sec | |
Firing Order | 1-5-3-6-2-4 | |
Performance Date of Cummins 6CT8.3-GM115 Marine Auxiliary Engine | ||
Rated Output/Speed | 115/KW/155HP/1500RPM | |
Standby Output/Speed | 127KW/170HP/1500RPM | |
Max torque/speed | ||
Frequency(HZ) | 50 | |
Fuel Consumption/rated output | 209 g/KW.h | |
Fuel Consumption/standby output | 212 g/KW.h | |
4BTA3.9-GM47 | AD fuel pump,Rated power47KW, speed1500rpm,SAE 3 flywheel, turbo, aftercooler | SO11070(electric starter) |
SO13280(air starter) | ||
SO11071-4 | ||
6BT5.9-GM83 | electric fuel pump ,Rated power83KW, speed1500rpm,SAE 3 flywheel, turbo. | SO10938(electric starter) |
SO10940(air starter) | ||
SO10939-3 | ||
SO10939-4 | ||
6BTA5.9-GM100 | PB pump,GACelectric speed aduster,Rated power100KW, speed1500rpm | SO11104(electric starter) |
6BTA5.9-GM100 | PB pump,GACelectric speed aduster,Rated power100KW, speed1500rpm | SO11105(air starter) |
6BTAA5.9-GM115 | Rated power115KW, speed1500rpm | SO11126-3 |
6BTAA5.9-GM115 | Rated power115KW, speed1500rpm | SO11126-4 |
6CT8.3-GM115 | A type pump,Rated power115KW, speed1500rpm,turbocharger. | SO20722(electric starter) |
SO20782(air starter) | ||
SO20795-3 | ||
SO20795-4 | ||
6CTA8.3-GM155 | P type pump GAC electric speed aduster pump,Rated power155KW, speed1500rpm,turbo | SO20730(electric starter) |
SO20864(electric starter with emission) | ||
SO20783(air starter) | ||
SO20937(air starter) | ||
SO20796-3 | ||
SO20796-4 | ||
SO20938-3( with emission) | ||
SO20938-4( with emission) | ||
6LTAA8.9-GM200 | P type pump GACelectric speed aduster,Rated power200KW, speed1500rpm | SO30763-1(electric starter with emission) |
SO30763-2(air starter with emission) | ||
SO30197-3 | ||
SO30197-4 |
Packing & Delivery
wooden box
