Product Overview
Description
Insturment features
Features
◆ Adopt excellent unlimited far-high magnification optical system.
◆ Using LED light source lighting system to ensure high brightness,long life.
◆ Adopt no intervening light rod drive workbench to ensure measurement accuracy.
◆ High working distance, use stepper motor to lift, easy to adjust, come with DIC device slot.
◆ Unique thick, microcomputer, fine tune 0.0001 mm per grid.
◆ Closer to the flexibility of the user, the user's part upgrade does not require professional, the user can do its own operation.
◆ Using LED light source lighting system to ensure high brightness,long life.
◆ Adopt no intervening light rod drive workbench to ensure measurement accuracy.
◆ High working distance, use stepper motor to lift, easy to adjust, come with DIC device slot.
◆ Unique thick, microcomputer, fine tune 0.0001 mm per grid.
◆ Closer to the flexibility of the user, the user's part upgrade does not require professional, the user can do its own operation.
◆Supporting dark field observation, DLC differential observation Z-axis automatic focus test Suitable for LED display, liquid crystal display, touch screen and other fields
◆ Can directly measure 12 kinds of elements (point, line, circle, arc, ellipse, rectangle, trough, ring, distance, angle, open
cloud line, closed cloud line)
cloud line, closed cloud line)
◆ There is an automatic deburring function, which can be accurately found for dark and unclear borders.
Specifications and parameters
Model | V800 |
physical dimension | 1500*800*1750mm |
Movement stroke (mm) | X:900mm Y:500mm |
Measurement and aiming system | 2/3"sony senser, digital color camera, 2560*1920 |
Off-site accuracy | 3+（L/1000）μm |
In-field accuracy | ±1μm |
Face backlight | 75 inches (3 rows and 4 columns can be partitioned control) |
Working height | 850mm |
Reflective lighting system | High-definition LED reflective lighting |
Transmission lighting system | High-definition LED transmission lighting |
Instrument weight (kg) | 900Kg |
Instrument power | 220V±10%（AC）50HZ |
Optical system | LV-TI3 Trinocular Eyepiece Tube CH (with Erect Image) |
Eyepiece CFI 10x / CN | |
Eyepiece CFI 10x CM Eyepiece with Crosshairs / CN | |
Nikon L-NU5A Motorized Universal Quintuple Nosepiece | |
Nikon YM-PO Polarizer for LV-U EPI | |
Nikon L-DIHC DIC Slider DIC prism | |
Objective lens model parameters: 2.5X:Nikon CFI L Plan EPI 2.5X, (NA/WD : 0.075/8.80mm) 5X:Nikon CFI LU Plan FLUOR BD 5X (NA/WD : 0.15/18.0mm) 10X:Nikon CFI LU Plan FLUOR BD 10X (NA/WD :0.30/15.0mm) 20X:Nikon CFI LU Plan FLUOR BD 20X (NA/WD : 0.45/4.5mm) 50X CR:Nikon CFI L Plan EPI 50x CR (NA/WD : 0.70/3.9-3.0mm) 100X CR:Nikon CFI L Plan EPI 100x CR (NA/WD : 0.85/1.2-0.85mm) | |
Type A：5×、10×、20× CR、50x CR 、100x CR | |
Scale | Imported RENISHAW metal grating ruler with resolution 0.0001mm |
XYZ axis drive | THK high precision linear guide and THK grinding grade ball screw |
Drive | X\\Y manual, Z-axis Panasonic servo motor |
Machine body | Marble |
Photoelectric limit | Japan Omron |
Machine body | Marble |
