Product Overview
Description
Product Description
Guangdong Manufacturer Handheld Portable Screw Locking Machine
The machine is versatie and universal. The screw is sent to the screwlock head by air blowing. Just press the electric screwdriver bit to the unlocked position and gently press down to complete the lock task. It helps eliminating the repeated actions such as manual self-pickup the screws. At the same time, you can free up your hand to hold the product. It increased the working efficiency and save time as well as labor cost.
Machine Features
1. High efficiency：when using this manual screw locking machine, all processes can be operated with only one hand. He only needs to find the correct screw hole and tighten the screw within a second. This is a semi-automatic method that can save labor costs and increase productivity.
2. The machine adopts turbo paper feeding method with low noise. The feeding process of the machine is stable, fast, high-efficiency, and quality assurance. The machine can quickly screen out the screws of the opposite sex. Once there are screws of the opposite sex, the alarm will automatically sound with a buzzer.
3. The machine has long-term stability：The screws will not get stuck and the machine will work. During the locking process, the new screw will be automatically transported to the locking opening of the screwdriver. If the torque is insufficient, the screws will not be transported, and the problem will be known and resolved quickly in a few seconds.
4. Clean and pollution-free：Workers do not need to remove the screws manually, everything is automated, so the workers' hands will not secondly contaminate the product due to contact with the screws, nor will the screws be easily rusted due to sweating.
5. Durable：The machine can be used for many years. The key structures and components are all made from high-quality stainless steel and aluminum materials with special heat treatment. All pneumatic parts, screwdrivers and locks are brand new.
6. Intelligent production：the production schedule can be accurately grasped, tasks can be completed on time, and there is no need to recruit a large number of workers.
Details Images
Manufacturing Technique
1 | Machine Dimension | 360*250*195mm |
2 | Machine Net Weight | 13 kg |
3 | Working Power | AC 220V 50/60 Hz |
4 | Power Consumption | 30W |
5 | Usage Environment | -20℃ -40 ℃ |
6 | Working air pressure | 2--3KGF / cm² |
7 | Transport distance | 1-4 meters |
8 | Max feeding bin capacity | 3000 pcs (according to size ) |
9 | Screwdriver bit type | Std KILEWS or customized |
10 | Screw head model | Cross, PH, Cross, Star drive, Triangle, Hex,etc. |
11 | Suitable industry | Universal, almost suitable for all industries |
12 | Equipment compatible | Tolerance 0.5 mm, Length 5 mm |
13 | Screw models | M1, M2, M3, M4, M5 , M6 |
14 | Screw teeth diameter | 1.2, 1.4, 1.7, 2.0, 2.3, 2.6, 2.8, 3.0, 3.5, 4.0, 5.0 |
15 | Max screw length | 25 mm |
16 | Max screw head diameter | 5 mm |
17 | Locking speed | Max 60 pcs / minute, 1 screw in one second |
18 | Packing list | 1 x screw driver bit with lock, 1 x Host with screwfeeder |
Various screwdrivers will be customized built according to your screw models, shapes and locking products
Each machine will be tested and quality checked by QA before shipment.
Our Advantages
Why choose our machine
1. Versatile, rugged and are “automatic feeder ready”
2. Flexibility: Standard universal fixtures are suitable for a wide range of production requirements.
3. Extensive versatility: M1-M4 screw locking can be achieved by replacing the feed screw module.
4. Desktop type can be placed on the production line.
5. High-rigidity aluminum alloy multi-axis design ensures reliability and accuracy.
2. Flexibility: Standard universal fixtures are suitable for a wide range of production requirements.
3. Extensive versatility: M1-M4 screw locking can be achieved by replacing the feed screw module.
4. Desktop type can be placed on the production line.
5. High-rigidity aluminum alloy multi-axis design ensures reliability and accuracy.
Best option
6. More user-friendly touch screen or teaching pendant operation, easy to operate. External technical parameters and manual test
functions can be directly adjusted by the technician.
7. The screw locking mechanism can work without a teach pendant connection.
8. ODM or OEM is OK.
functions can be directly adjusted by the technician.
7. The screw locking mechanism can work without a teach pendant connection.
8. ODM or OEM is OK.
9. Provide profession suggestion of the handheld screw driver according to your screw bolt models and materials, as well as the locking products.
Recommend Products
Company Profile
Huizhou Shengyang Industrial Co., Ltd. is specialize in R&D and manufacturing electronic equipment industry manufacturing automation equipments.Our products including automatic welding machine,automatic screw locking machine, automatic screw tightening machine, automatic screw feeder machine, Turbine air blowing automatic feeder, Coordinate machine, Automatic dispenser, Peristaltic dispenser, Automatic glue filling machine, Automatic soldering machine,Led production automation line and Electronic automation assembly.We operate with our products with our own brand Techleader for our global customers and we also doing many OEM&ODM production for our customers.
For production quality management, we alwasys strictly follow the standards of double soft enterprise. The company has all kinds of processing equipment, can respond quickly according to customer needs, and guarantee the customer’s pre-sales and after-sales service. Our products are widely used in electronic information, communication industry, auto parts, household appliances, medical equipment, etc. After years of experience, our products have benefited a lot in the industry. We look forward to cooperating with you.Our customers are all over the world, including the United States, South Korea, Malaysia, Russia, Slovenia, Thailand, Philippines, India,Pakistan and other countries.
FAQ
1. What’s the minimum order quantity(MOQ)?
- Minimum 1 machine, small batch and large volumes are acceptable.
2. When can I get the quotation?
- We usually respond within 24 hours on working days receiving your messages. Then we will discuss the screw models and materials. After receiving samples for testing and evaluating, we will forward to you with quotation within one week.
3. Which is the safe payment method to trade?
- We accept T/T, LC, Paypal, Trade Assurance and Secure payment on Alibaba platform.
4. How long will it take to produce the machine?
- For standard machine, it will be 15 days for manufacturing, 30 days in hot season.
- For non-standard machine, it will be negotiated customized according to your requirements.
5. What’s the shipping method?
- We are able to ship worldwide where Ocean shipping or Air shipping can reach.
- Machines will be packed safely and protectively to ensure you will receive a brand new one.
6. How do you ensure quality control?
- We produce standard screw bolt drivers and feeding systems accodting to samples. So it's necessary to provide samples for us to test. We have experienced technical team to test and adjust the machines that fit for your locking task.
7. What's the warranty and after-sales service?
- We provide a period of A YEAR after the date of the original purchase.
- Minimum 1 machine, small batch and large volumes are acceptable.
2. When can I get the quotation?
- We usually respond within 24 hours on working days receiving your messages. Then we will discuss the screw models and materials. After receiving samples for testing and evaluating, we will forward to you with quotation within one week.
3. Which is the safe payment method to trade?
- We accept T/T, LC, Paypal, Trade Assurance and Secure payment on Alibaba platform.
4. How long will it take to produce the machine?
- For standard machine, it will be 15 days for manufacturing, 30 days in hot season.
- For non-standard machine, it will be negotiated customized according to your requirements.
5. What’s the shipping method?
- We are able to ship worldwide where Ocean shipping or Air shipping can reach.
- Machines will be packed safely and protectively to ensure you will receive a brand new one.
6. How do you ensure quality control?
- We produce standard screw bolt drivers and feeding systems accodting to samples. So it's necessary to provide samples for us to test. We have experienced technical team to test and adjust the machines that fit for your locking task.
7. What's the warranty and after-sales service?
- We provide a period of A YEAR after the date of the original purchase.
