Datasheet | Model | ACSNLD-14 | ||||
Input | Power Supply | 1P+N+PE | ||||
Rated Voltage | 230V AC | |||||
Rated Current | 64A | |||||
Frequency | 50/60Hz | |||||
Output | Output Voltage | 230V AC | ||||
Maximum Current | 2x32A | |||||
Rated Power | 2x7KW | |||||
User Interface | Charge Connector | Type 2/Type 1/GB/T | ||||
Enclosure | Galvanized steel | |||||
Left/Right Panel | Temper glass | |||||
LED Indicator | Green/Yellow/Red | |||||
LCD Display | 4.3'' screen | |||||
RFID Reader | Mifare ISO/IEC 14443 A | |||||
Start Mode | Plug&Play/RFID card | |||||
Emergency Stop | No | |||||
Communication | WiFi | No | ||||
Ethernet | No | |||||
3G/4G | No | |||||
OCPP | No | |||||
Sefety | Energy Meter | MID certified | ||||
RCD | 30mA Type A + 6mA DC | |||||
Ingress Protection | IP54 | |||||
Impact Protection | IK08 | |||||
Electrical Protection | Over current protection, Residual current protection, Short circuit protection, Ground protection, Surge protection, Over/Under voltage protection, Over/Under frequency protection, Over/Under temperature protection | |||||
Certification | CE | |||||
Certification Standard | EN/IEC 61851-1: 2017, EN/IEC 61851-21-2: 2018 | |||||
Warranty | 2 Years | |||||
Environment | Installation | Floor-stand | ||||
Work Temperature | -30℃~+50℃ | |||||
Work Humidity | 5%~95% | |||||
Work Altitude | <2000M | |||||
Package | Product Dimension | 1450*350*160MM (H*W*D) | ||||
Package Dimension | 1500*550*170MM (L*W*H) | |||||
Net Weight | 25KG | |||||
Gross Weight | 27KG | |||||
External Package | Wood case | |||||
