DC 12v 200a Power Supply 6v 300ma DC Adaptor DC 5v Adapter
- Category: >>>
- Supplier: Ningbo Antow Electronics Co. Ltd.
Share on (1600218649780):
Product Overview
Description
Product Description
Dc 12v 200a Power Supply 6v 300ma Dc Adaptor Dc5v Adapter
Product Description
Features:
-
AC to DC power adapter
-
Wall mount / plug in type, with EU/USA/Australian/UK/KC pin
-
Safety certifiates of CE, GS,FCC, KC, Smark, SAA etc.
-
Engergy efficiency level V, VI
Specifications:
| Input | |
| Input voltage, frequency | 100-240VAC, ±10%, 50-60Hz, ±3Hz |
| Input Current | 0.19A Max. |
| Input Plug | EU/USA/Korea/UK/Australia/Japan etc. |
| Output | |
| Line /Load Regulation | ±1% / ±5% |
| Ripple & Noise | Max 1% ~ 2% of Output Voltage (mVp-p), at Full Load |
| Efficiency ( avg ) | ≥86.88%, meet DoE Level VI; ≥79.03%, meet CoC V5.0 Tier 2 |
| No-loading Power Consumption | 100mV max. ( Level VI) ; 75mV max. ( CoC V5.0 Tier 2) |
| Output | 3 to 24Vdc, 0.1 to 1A, 6W max. |
| Protection | |
| Short Circuit/Over Current/Over Heat Protection | Capable of self-protect and auto recovery when faults be removed or temperature goes down |
| Environment | |
| Temperature | Operating: 0 ~ 40 °C ; Storage: -20 ~ 85 °C |
| Humidity | Operating: 8% ~ 90% RH; storage: 5% ~ 95% RH non condensing |
| Safety Approvals & EMC ( EMI, EMS ) | |
| RoHS | 2011/65/EU (RoHS 2.0) |
| CE, GS/ CB | EN/IEC62368, EN61347, EN61558, EN60335, EN60065, etc. |
| EMI: | EN55023, EN55024, EN55015, EN61000-3-2,FCC Part 15 etc. |
| Mechanical & Packing | |
| Case Size | 59L X 27W X 40H mm |
| Packing | 1 pcs/box, 100 pcs/carton |
| Carton Size/Gross Weight | 53x43x17cm/0.39cbm/10kgs |
Certifications
Company Information
Packaging & Shipping
Our Services
FAQ
1, What's the payment term?
We normally quote prices base on FOB Ningbo, Shanghai. CNF, CFA, CIF, etc.
2, How ong is your product warranty?
Our warranty is 2 or 3 years.
3, Can I buy customized products?
Yes, we provide OEM/ODM products;
4, Do you offer free samples to for testing?
Yes, we would be glad to provide new customers with 1-2 pcs free samples.
but we might charge express cost, or you can provide us your express account for express cost collection.
5, What is the lead time of sample?
5-7 working days.
