1 5 Tons JDF5040XLCJ6 specialshun vaccine cold chain transport truck freezer car

Share on:

Price:$19,990.00 - $21,000.00
Price in USD:Details


Product Overview


Product Description

JMC JDF5040XLCJ6 specialshun vaccine cold chain transport truck factory direct sales
Product number: ZR3PA6JC01E
Chinese Brand: Jiangte Brand
Main technical parameters of JDF5040XLCJ6 refrigerated truck
Dimensions: 5652×1972×2460, 2240 (mm)
Total weight: 3510 (Kg)
Load quality utilization factor: 0.55
Curb weight: 2260 (Kg)
Rated load quality: 1055 (Kg)
Chassis emission standards China VI
Front passenger: 3 (people)
Rated passenger capacity: (person) Anti-lock braking system: Yes
Approach angle/departure angle: 22.1/23.7(°)
Front suspension/rear suspension: 982/1100(mm)
Axle load: 1475/2035
Wheelbase: 3570(mm)
Number of axes: 2
Maximum speed: 120(km/h)
Fuel consumption: 8.3(L/100Km)
Number of springs: -/3
Number of tires: 4 (pieces)
Tyre specification: 225/65 R16C
Front track: 1692(mm)
Rear wheelbase: 1700(mm)
Engine parameters
Engine model: Engine manufacturer
Displacement (ml): 2771
Power (kw)/Horsepower (PS): 85/115
Fuel type: diesel

Main vehicle configuration
1 Anti-lock braking system (ABS)
2 Original Isuzu National VI Engine
4 Central door lock
5 Side sliding doors fully open
6 Cab 3 seats
7 Cab airbag
8 Power windows in the cab
9 Rear double door
10 USB and radio sound system
11 Remote control key
12 Rear blind window
13 5-speed manual, front and rear drive
14 LED lights in the passenger area provide sufficient brightness for passengers
15 Rear cabin LED lighting provides sufficient brightness for staff
16 Inner layer 304 stainless steel Nationally recognized food grade stainless steel, with good corrosion resistance, heat resistance, low temperature strength and mechanical properties
17 Four-sided ventilating troughs Ensure that the bottom and sides of the cargo are not in complete contact with the car body to ensure the cold air circulation of the whole car body (especially the bottom)
18 Ultraviolet disinfection lamp can effectively ensure the disinfection of the car body
19 Domestic-made chiller unit (overhead) The temperature is automatically adjusted to achieve the perfect combination of power and refrigeration. It can be operated in the cab, which is simple and convenient
20 Stainless steel door locks have the characteristics of light weight, high strength and corrosion resistance.
21 Patterned aluminum plate (floor) Improve the anti-skid, wear-resistant and easy-to-clean floor of the refrigerator compartment Optional configuration (price reference)

1 Reversing radar Reversing safety auxiliary equipment, which can effectively remind the driver to approach obstacles when reversing
2 Driving recorder Records related information such as images and sounds during the driving of the vehicle
3 Imitation leather seats provide a more comfortable ride
4.Temperature and humidity recorder with over-temperature alarm, temperature display, cabin temperature can be observed in the cab, with fault self-check and code display, can be connected to a computer, with storage statistics function;
5.Cold King Refrigerator (Top-mounted) The refrigeration unit has only single-cooling function, the lowest temperature can reach -15℃; when equipped with heating system function, the temperature of the refrigerator can be controlled between -15 ℃ and +20 ℃
6.Carrier Refrigerator (Overhead) The refrigeration unit has only single cooling function, and the lowest temperature can reach -15℃; when equipped with heating system function, the temperature of the refrigerator can be controlled between -15 ℃ and +20 ℃
7 Rear compartment heating system The refrigeration unit only has a single cooling function, the lowest can reach -15℃; if the rear compartment is required to have a heating function, it needs to be equipped with a heating system (the temperature of the refrigerator can be controlled between -15 ℃ and 20 ℃);
8 Shelf dividers effectively classify and fix goods
9 GPS navigation integrated machine for vehicle navigation and positioning
10 Power distribution system Equipped with a 220V external power supply for the power distribution system, it can work normally when the engine does not start to ensure that the temperature in the compartment is maintained at a constant temperature.

Packing & Delivery

waxed before shipping

Company Profile

CLW GROUP TRUCK ,The Top1 special trucks maufacturer in China ,


1. who are we?
We are based in Hubei, China, start from 2016,sell to Domestic Market(30.00%),Eastern Asia(20.00%),South Asia(20.00%),Africa(9.00%),Mid East(9.00%),South America(2.00%),Southeast Asia(2.00%),Central America(2.00%),North America(1.00%),Oceania(1.00%). There are total about 1000+ people in our office.

2. how can we guarantee quality?
Always a pre-production sample before mass production;
Always final Inspection before shipment;

3.what can you buy from us?
Road Sweeper,Garbage truck,Refrigerator truck,LPG tank truck,Truck Cargo Crane

4. why should you buy from us not from other suppliers?
CLW GROUP TRUCK ,China Top1 Special trucks Manufacturer, Top500 companies in China,Have more than 9000 workers , more than 150,000 square metters workshop, more than 13 years export experice,Can design and produced all kinds of the special trucks

5. what services can we provide?
Accepted Delivery Terms: FOB,CFR,CIF,EXW;
Accepted Payment Currency:USD,EUR,HKD,CNY;
Accepted Payment Type: T/T;
Language Spoken:English,Chinese

Contact Us

CLW Group Truck
Director: Janet Zhang
Mobile:0086-186 7273 0321
Email: [email protected]
We chat:0086-186 7273 0321
WhatsApp: 0086-186 7273 0321
