GPS DIFFERENTIAL RTK GNSS RECEIVER SURVEY BASE AND ROVER DGPS PRICE STONEX S9 USED SECOND HAND ROVER WITH BATTERY CHARGER
- Category: >>>
- Supplier: Suzhou Super Gis Technology Co. Ltd.
Share on (1600222348825):
Product Overview
Description
Product Description
Second hand STONEX S9 gps rtk 75% new - 95%new,
INCLUDING :
ROVER 1PC
ANTENNA 2PCS
BATTERY 2PCS
CHARGER 1PC
CABLE 1PC
INCLUDING :
ROVER 1PC
ANTENNA 2PCS
BATTERY 2PCS
CHARGER 1PC
CABLE 1PC
S9 III Plus GNSS is the result of the continuous evolution of the STONEX GPS integrated receivers. Featuring a new, high accuracy multi constellation antenna, a powerful UHF transmitter and the GSM 3G WCDMA modem, for a fully integrated communications choice,
combined with a light and modern design, STONEX S9 III Plus improves the field performances, giving immediate and reliable positioning even in difficult environments. Compatible with GPS, GLONASS, GALILEO, COMPASS, no limitation will slow down your field operations.
A SCALABLE SOLUTION: NO; THANK YOU!
Fully complete are not just words: no options are available for STONEX S9 III Plus GNSS, that combines an embedded 220 channels GNSS board, accurate and fast in satellite fixing, UHF radiomodem, GSM 3G modem for GPS network connections, Bluetooth™ device for completely cable-free operations. S9 III Plus GNSS can work as Base, transmitting to one or more Rovers, and as GPS network Rover:the complete set of communications options give you a completely free operating choice from the beginning, no after sale options are requested.
TOTAL FLEXIBILITY AT YOUR SERVICE
The integrated UHF transmitting and receiving radiomodem, with output power up to 2W, makes STONEX S9 III PLUS GNSS a powerful source of GPS corrections: constructions sites, cadastral and land survey, marine and hydrographic applications, take a big advantage using one high accuracy transmitting GPS, combined with Rovers. Moreover, S9III Plus is compatible with several GPSs:
Satel™ and TRIMTALK™ 450S are just some examples of the supported protocols. And where a GPS Network is available, S9 III Plus GNSS is the perfect rover, using the 3G integrated modem.
RELIABLE. FAST, CABLE FREE
The IP67 certification, combined with a high shock resistance - S9 III Plus GNSS survives even after a 2 m drop on concrete -guarantee the maximum strength and the best water/dust-tight. With its short initialization time, S9 III Plus GNSS lets you save time everyday, every job; And when the GPS signal is lost, the advanced STONEX technology used in the new S9 III Plus GNSS reduces to a moment the re-initialization time, while positioning accuracy, checked from the field software, gives you a totally comfortable feeling of a good result.
The Bluetooth™ device, make S9 III Plus a fast and completely cable free one man system for every kind of topographic job.
combined with a light and modern design, STONEX S9 III Plus improves the field performances, giving immediate and reliable positioning even in difficult environments. Compatible with GPS, GLONASS, GALILEO, COMPASS, no limitation will slow down your field operations.
A SCALABLE SOLUTION: NO; THANK YOU!
Fully complete are not just words: no options are available for STONEX S9 III Plus GNSS, that combines an embedded 220 channels GNSS board, accurate and fast in satellite fixing, UHF radiomodem, GSM 3G modem for GPS network connections, Bluetooth™ device for completely cable-free operations. S9 III Plus GNSS can work as Base, transmitting to one or more Rovers, and as GPS network Rover:the complete set of communications options give you a completely free operating choice from the beginning, no after sale options are requested.
TOTAL FLEXIBILITY AT YOUR SERVICE
The integrated UHF transmitting and receiving radiomodem, with output power up to 2W, makes STONEX S9 III PLUS GNSS a powerful source of GPS corrections: constructions sites, cadastral and land survey, marine and hydrographic applications, take a big advantage using one high accuracy transmitting GPS, combined with Rovers. Moreover, S9III Plus is compatible with several GPSs:
Satel™ and TRIMTALK™ 450S are just some examples of the supported protocols. And where a GPS Network is available, S9 III Plus GNSS is the perfect rover, using the 3G integrated modem.
RELIABLE. FAST, CABLE FREE
The IP67 certification, combined with a high shock resistance - S9 III Plus GNSS survives even after a 2 m drop on concrete -guarantee the maximum strength and the best water/dust-tight. With its short initialization time, S9 III Plus GNSS lets you save time everyday, every job; And when the GPS signal is lost, the advanced STONEX technology used in the new S9 III Plus GNSS reduces to a moment the re-initialization time, while positioning accuracy, checked from the field software, gives you a totally comfortable feeling of a good result.
The Bluetooth™ device, make S9 III Plus a fast and completely cable free one man system for every kind of topographic job.
SurPad 4.0
Android - Field Data Collection Software
SurPad4.0 is a GNSS surveying and mapping software. It is designed based on years of accumulated market experiences, combining them with the international mainstream of surveying and mapping data acquisition function of the software, integrating RTK control, GIS data collection and road design and layout into one place. The software has outstanding graphic interaction, powerful functions and is able to humanize operation process.
Android - Field Data Collection Software
SurPad4.0 is a GNSS surveying and mapping software. It is designed based on years of accumulated market experiences, combining them with the international mainstream of surveying and mapping data acquisition function of the software, integrating RTK control, GIS data collection and road design and layout into one place. The software has outstanding graphic interaction, powerful functions and is able to humanize operation process.
Specification
RECEIVER | ||
Channels | 220 | |
GPS: Simultaneous LI C/A, L2E, L2C,L5 | ||
GLONASS: Simultaneous LI C/A, LIP, L2 C/A (GLONASS M Only), L2P | ||
SBAS: Simultaneous LI C/A, L5 | ||
Satellite Tracked | GALILEO (reserved): Simultaneous LI BOC, E5A, E5B, E5AltB0Cl | |
COMPASS: Bl (QPSK), Bl- MBOC (6,1, 1/11), Bl-2 (QPSK), B2 (QPSK), B2-B0C (10,5), B3 (QPSK),B3B0C (15,2,5), L5 (QPSK) | ||
Signal Reacquisition | < 1 sec | |
RTK Signal Initialization | typically < 10 s | |
Hot Start | typically < 15 s | |
Initialization Reliability | >99.9% | |
Internal Memory | 256 MB | |
Micro SD Card | 4 GB Internal Memory (Over 60 days of raw static data storage with recording sample every 1 second) | |
POSITIONING1 | ||
HIGH PRECISION STATIC SURVEYING (Long time observations) | ||
Horizontal | 2.5 mm + 0.3 ppm RMS | |
Vertical | 5 mm + 0.5 ppm RMS | |
CODE DIFFERENTIAL POSITIONING | ||
Horizontal | 0.25 m + 1 ppm RMS | |
Vertical | 0.45 m + 1 ppm RMS | |
SBAS POSITIONING (Typical) | ||
Horizontal | 0.5 m RMS | |
Vertical | 0.85 m RMS | |
REAL TIME KINEMATIC (< 25Km) - NETWORK SURVEYING3 | ||
Fixed RTK Horizontal | 10 mm + 1 ppm RMS | |
Fixed RTK Vertical | 20 mm + 1 ppm RMS | |
COMMUNICATION 7-pins Lemo and 5-pins Lemo Connectors I/O interfaces. Multicable with USB interface for connecting with PC Bluetooth Device 2,4 GHz class II: maximum range is 50 m Reference Outputs CMR, CMR+, sCMRx, RTCM 23, RTCM 3.0, RTCM 3.1 ASCII (NMEA-0183) GSV, AVR, RMC,~ Navigation Outputs HDT, VGK, VHD, ROT, GGK, GSA, ZDA, VTG, GST, PJT, PJK, BPQ GLL, GRS, GBS |
INTERNAL RADIO | ||
Frequency Range | 403 - 473 MHz | |
Channel Spacing | 12.5KHz/25 KHz | |
Emitting Power | 0.5 /1/2 W | |
Maximum Range | 3-4 Km (urban environment), 5-6 Km with optimal conditions4 | |
Protocol | Transparent EOT/EOC/FSL SATEL, South, StonexType 1, TRIMTALK ll/lle, TRIMMARK 3, TRIMTALK 450S | |
WIRELESS MODULE | ||
Band | GSM/GPRS/EDGE : 850/900/1800/1900 MHz WCDMA/HSDPA : 2100/1900/850 MHz | |
Output Power | GSM850, EGSM900 : 33 dBm(2W) GSM1800, PCS1900 : 30dBm(lW) WCDMA : 23 dBm | |
POWER SUPPLY | ||
Battery | 2500 mAh high capacity Lithium battery, Voltage 7.2 V | |
Voltage | 9 to 15 V DC external power input with over-voltage protection | |
Working Time in Static Mode (GPS+GLONASS) | 7 hours | |
Working time in GSM RTK with Cable Connection (GPS+GLONASS) | 6.5 hours | |
Working time in wireless network RTK with Bluetooth connection (GPS+GLONASS) | around 4 hours | |
Charge time | typically 7 hours | |
Power consumption | <3.8W | |
Remaining time battery light blinking | 1 hour | |
PHYSICAL SPECIFICATION | ||
Weight | 1.2 Kg with internal battery, radio standard UHF antenna | |
Operating Temperature | -30°C to 60°C (-22°F to 140°F) (internal radio TX 50°C) | |
Storage Temperature | -40°C to 80°C (-40°F to 176°F) | |
Waterproof/Dustproof | IP67. Protected from temporary immersion to depth of 1 meter and from 100% humidity | |
Shock Resistance | Designed to survive a 2 m pole drop on concrete | |
Vibration | Vibration resistance | |
Winter Grade Option | Operating at -40°C (-40°F) | |
