Low Price Wholesale High Quality And High Efficiency Solar Panels

Product Overview

Description

KEY FEATURES

· High module efficiency through

superior manufacturing technology

· No power loss thanks to improved temperature co-efficient caused by 5 busbar solar cell

· Strictly control the micro-crack of solar cells and the other non visible defect of internal modules

· Module can bear snow loads up to 5400Pa

and wind loads up to 2400Pa

· Manufactured according to and certified international I Quality

and Environment Management System

· Using advanced low reflection and high light transmission glass and cell sheet surface cutting technology, in the weak light environment can also play a good performance.

Model	MGS-265P6-20
Maximum Power at STC(Pmax)	265W
Optimum Operating Voltage (Vmp)	31.32 V
Optimum Operating Current (Imp)	8.463 A
Open-Circuit Voltage    (Voc)	38.51 V
Short-Circuit Current  (Isc)	8.890 A
Solar Cell Efficiency   (%)	18.51
Solar Module Efficiency  (%)	16.29
Operating Temperature	-40to85℃
Maximum System Voltage	DC1000
Maximum Series Fuse Rating	15A
Power Tolerance	0~+3%
STC:Irradiance 1000W Per square meter,Modules Temperature 25℃,AM=1.5
