vertical lathe machine CK5240 cnc vertical lathe machine metal
- Category: >>>
- Supplier: Dalian Daji Cnc Machine Tool Sales Co. Ltd.
Share on (1600224947709):
Product Overview
Description
| Please pay attention! All products in this store are customized products, not directly ordered products. The specific parameters and appearance shall be subject to the communication between both parties! | |
| Max. Swing over bed mm | φ1600/2000/2500/3200/4000/5000/6300 |
| Table diameter mm | 1400/1800/2300/3000/3800/4800/6100 |
| Max. height of work-piece mm | 1000..3150 |
| Max. weight of wok-piece t | 5t..50t |
| Tool bar size mm | 40×40/50×50 |
| Main motor power kW | 30../..100 |
| Max. cutting force of tool post N | 25000 |
| Max. torque of working table N.m | 25000 |
| Speed range of work table r/min | 5-160r/min |
| Step of work table speed | 16 |
| Tool post feed range mm/min | 0.8-86 |
| Step of tool post feeds | 12 |
| Tool post travel mm | horizontal 915 /Vertical 800 |
| Tool post swing angle | ±30° |
| Side tool post travel mm | horizontal 630 Vertical 900 |
| Tool post rapid move speed mm/min | 1800 |
| Crossbeam lifting speed mm/min | 350 |
| Crossbeam lifting motor kW | 2.2 |
| Size & weight mm kg | 2830 × 2670 × 3010mm 13000kg |
| Standard configuration | workbench, Knife clip, Chuck claw, Hexagon nut, T-slot screw, Anchor bolt, Washer, A set of keys and tools for machine tool maintenance, English documents |
| Optional configuration | CNC Fanuc CNC Siemens, Side tool post travel, DRO |
 |  |
Company Profile
FAQ
1.What's your advantage?
A: Honest business with competitive price and professional service on export process.
2. How I believe you?
A : We consider honest as the life of our company, Besides, there is trade assurance from Alibaba, your order and money will be well guaranteed.
3.Can you give warranty of your products?
A: Yes, we extend a 100% satisfaction guarantee on all items. Please feel free to feedback immediately if you are not pleased with our quality or service.
4.Where are you? Can I visit you?
A: Sure,welcome to you visit our factory at any time.
5.How about the delivery time?
A: Within 35-45 days after we confirm you requirement.
6.What kind of payment does your company support?
A: T/T, 100% L/C at sight, Cash are all accepted if you have other payment,please contact me.
