HobbyWing waterproof XRotor X8 engine Power system brushless motor for agricultural drone
- Category: Aircraft >>>
- Supplier: Shenzhen,Top-Peak,Electronics,Co.,Ltd.
Share on:
Product Overview
Description
Product Description
Specification
Product Name: X8 Power System Combo
Max. Thrust: 15.3kg/Axis (48V, Sea Level )
Recommended LiPo Battery: 12S LiPo
Propeller
Diameter×Pitch: 3090
Weight: 180g
Max. Thrust: 15.3kg/Axis (48V, Sea Level )
Recommended LiPo Battery: 12S LiPo
Combo Weight: 1040g
Waterproof Rating: IPX7
Operating Temperature: -20℃~65℃
Recommended Takeoff Weight: 5-7kg/Axis(48V,Sea Level)
Motor
Stator Size: 81*20mm
KV Rating: 100KV
O.D of Carbon Fiber Tube: Φ35mm/Φ30mm (*Tube Adapter will be Needed)
Bearing: NSK Ball Bearing (Waterproof)
ESC
Recommended LiPo Battery: 6-12S LiPo
PWM Input Signal Level: 3.3V/5V (Compatible )
Throttle Signal Frequency: 50-500Hz
Operating Pulse Width: 1100-1940 μs (Fixed or cannot be Programmed )
Max. Input Voltage: 52.2V
Max. Input Current (Cont.): 80 A(w/ Good Heat Dissipation )
Max. Peak Current (10s): 100 A (w/ Good Heat Dissipation )
BEC: No
Nozzle Mounting Holes: Φ28.4mm-2*M3
Waterproof Rating: IPX7
Operating Temperature: -20℃~65℃
Recommended Takeoff Weight: 5-7kg/Axis(48V,Sea Level)
Motor
Stator Size: 81*20mm
KV Rating: 100KV
O.D of Carbon Fiber Tube: Φ35mm/Φ30mm (*Tube Adapter will be Needed)
Bearing: NSK Ball Bearing (Waterproof)
ESC
Recommended LiPo Battery: 6-12S LiPo
PWM Input Signal Level: 3.3V/5V (Compatible )
Throttle Signal Frequency: 50-500Hz
Operating Pulse Width: 1100-1940 μs (Fixed or cannot be Programmed )
Max. Input Voltage: 52.2V
Max. Input Current (Cont.): 80 A(w/ Good Heat Dissipation )
Max. Peak Current (10s): 100 A (w/ Good Heat Dissipation )
BEC: No
Nozzle Mounting Holes: Φ28.4mm-2*M3
Propeller
Diameter×Pitch: 3090
Weight: 180g
Packing & Delivery
Hobbwing XRotor X8 Power System Combo x 1
Company Profile
Shenzhen Top-Peak Electronics Co., Ltd is one of the leading drone R&D and manufacturers in China, which has been focused on drones since 2011. "Top-Peak" is our company name and "SINOCHIP" is our brand name. We offer toy drones,
photography drones and professional drones which can be used for agriculture, transportation, security, police, surveillance and military, etc.
We have our R&D team who has experience in design and development of drones for over 15 years. We have filed our technology patent and Trade Mark"SINOCHIP" in China. In June 2015, we were certified and rewarded "National High-Tech Enterprises" by our local government. In July 2017, we passed the certification of Intellectual Property Management System by Beijing Certification Company.
Good quality, competitive price, on-time delivery and considerate service are the core factors of SINOCHIP. With our experienced sales team in English, Spanish and Russia, our products are hot selling in Asia, Europe, North America and South America. We welcome our clients from different parts of the world to take the cooperation with us for long-term partnership, win-win business and create our bright future!
photography drones and professional drones which can be used for agriculture, transportation, security, police, surveillance and military, etc.
We have our R&D team who has experience in design and development of drones for over 15 years. We have filed our technology patent and Trade Mark"SINOCHIP" in China. In June 2015, we were certified and rewarded "National High-Tech Enterprises" by our local government. In July 2017, we passed the certification of Intellectual Property Management System by Beijing Certification Company.
Good quality, competitive price, on-time delivery and considerate service are the core factors of SINOCHIP. With our experienced sales team in English, Spanish and Russia, our products are hot selling in Asia, Europe, North America and South America. We welcome our clients from different parts of the world to take the cooperation with us for long-term partnership, win-win business and create our bright future!
FAQ
1.Can i have a sample order ?
Yes you can .We accept sample order to test and check the quality of goods.
2. Can i get some discount if i order large quantities ?
4. What services can we provide?
Accepted Delivery Terms: FOB,CFR,CIF,EXW,Express Delivery；
Accepted Payment Currency:USD,EUR,JPY,CAD,AUD,HKD,GBP,CNY,CHF;
Accepted Payment Type: T/T,L/C,MoneyGram,PayPal,Western Union,Cash,Escrow;
Language Spoken:English,Chinese
2. Can i get some discount if i order large quantities ?
Yes , Cheaper price is available if the order quantity is large .
3.What is your delivery time ?
3.What is your delivery time ?
Around 7 -14 working days , depending on the quantity or if we have stocks .
4. What services can we provide?
Accepted Delivery Terms: FOB,CFR,CIF,EXW,Express Delivery；
Accepted Payment Currency:USD,EUR,JPY,CAD,AUD,HKD,GBP,CNY,CHF;
Accepted Payment Type: T/T,L/C,MoneyGram,PayPal,Western Union,Cash,Escrow;
Language Spoken:English,Chinese
