High Precision Straight shank ER collet chuck M/A/UM Type For CNC machine C12 ER11A/M 80

Product Overview

Description

High Precision Straight shank ER collet chuck M/A/UM Type For CNC machine C12 ER11A/M-80

Dear customers welcome you to our store, we will give you the best service, wish you a happy shopping.

Specification

Product Name: C10 C16 C20 C25 C32 ER8 ER11 ER16 ER20 ER25 ER32 Extension rod Brand

Precision : ≤0.003mm Material: 40CrMnTi Steel Applicable machine: CNC, computer gong, high speed machine, lathes, engraving machines, milling machines



	STRAIGHT  SHANK  COLLET CHUCK  WITH  MINI  NUT
Order No.		d	D		D1		L		L1
ER8M-10×95-17		1-5	10		12		95		17
ER8M-10×120-7		1-5	10		12		120		17
ER8M-16×100-17		1-5	16		12		100		17
ER11M-12×95-28		1-7	12		16		95		28
ER11M-12×150-30		1-7	12		16		150		30
ER11M-16×100-19		1-7	16		16		100		19
ER11M-16×150-19		1-7	16		16		150		19
ER16M-12×50-36		1-10	12		22		50		36
ER16M-12×100-40		1-10	12		22		100		40
ER16M-16×80-37		1-10	16		22		80		37
ER16M-16×150-40		1-10	16		22		150		40
ER16M-20×50-35		1-10	20		22		50		35
ER16M-20×100-25		1-10	20		22		100		25
ER16M-20×150-25		1-10	20		22		150		25
ER20M-16×60-40		1-13	16		28		60		40
ER20M-16×100-40		1-13	16		28		100		40
ER20M-16×150-40		1-13	16		28		150		40
ER20M-20×80-40		1-13	20		28		80		40
ER20M-20×100-40		1-13	20		28		100		40
ER20M-20×120-40		1-13	20		28		120		40
ER20M-20×150-40		1-13	20		28		150		40
ER25M-20×150-50		1-16	20		35		150		50
ER25M-25×145-45		1-16	25		35		145		45
