Полуавтоматический Вакуумный Ламинатор с канавками/оборудование для производства картона
- Category: Paper Product Making Machinery >>>
- Supplier: Cangzhou,Jialong,Import,And,Export,Co.,Ltd.
Share on:
Product Overview
Description
Semi automatic vacuum flute laminator machine/Carton Making Machinery
Major feature:The high speed, high accurate flute laminate which developed by our Company is the most advanced in our country.
This machine operation is stable, joint accurate, easy operation, need not skilled workers.
This machine is used for making Print paper and bottom paper(card paper, corrugated paper) match together accurately, then the paper level off, and high precision.
1. Feeding of high table, automatic feeding for bottom sheet, elastic front register, simple operation.
2. just need one person to feed the paper. It has low request to paper, suitable for laminating paperboard to bottom paperboard, ABCDE Flute corrugated cardboard. Even filmed paper can be laminated.
3. Top sheet forwarded by manual on high table and the sheet can be piled up to 1.8m.
4. Bottom sheet is automatically fed; the two sheets are piled freely; High efficiency
5. Advanced elastic front register is used for location, high register precision, bottom paper will never exceed. When laminating, it is very easy to make top paper and bottom paper alignment, or top sheet exceeded.
6. Fully automatic glue supply system: glue will be automatically supplied during lamination, and recovered, avoiding glue wasted.
7. Scientific design for linear speed of metering roller, avoiding glue thrown when high-speed running.
7. The whole machine adopts PLC control system, compared with other time-delay device or middle relay control, the bottom paper is transferred more precise and stable, furthermore, speed is greatly increased, and circiut breakdown can automatically display and alarm.
8. Clean the lower roller in gluing section by blade with circulated water, complete cleaning, convenient to replace the blade
9. Floating movable pressing section is adopted to make the laminated paperboard smooth. This section can be moved front and back to take in paper conveniently.
10.. Gear rach is used to control the lift of water tray, which is easily taken out for cleaning.
Technological parameter:
model | TM-1300 | TM-1400 | TM-1500 | TM-1600 |
Max size of cover face | 1300x1100mm | 1400X1250mm | 1500X1250mm | 1600X1250mm |
Min size of cover face | 360x360mm | 360x360mm | 360x360mm | 360x360mm |
Economic speed | 0-100piece/min | 0-100piece/min | 0-100piece/min | 0-100piece/min |
precision | ≤±1mm | ≤±1mm | ≤±1mm | ≤±1mm |
power | 6kw | 6kw | 6kw | 6kw |
size | 8.8x1.95x1.5m | 8.8x2.05x1.5m | 8.8x2.15x1.5m | 8.8x2.25x1.5m |
weight | 3T | 3T | 3.5T | 3.5T |
FAQ
Q1: which company you are from ?
A1:I am from JIALONG PACKAGING MACHINERY CO.,LTD,We are professional manufacturer of corrugated carton machinery for more than 30 years.
Q2:where you company locate ?
A2:Our company located in Dongguang County, Cangzhou City, Hebei Province.
Q3:You are trade company or manufacture ?
A3:We are manufacture . and also have export company , because our factory can not export all kind of machine , but export company will can export all.
Q4: I want the machine for make the corrugated board ?
A4:Please tell to me the size,speed and how many ply corrugated board will make ? so i can supply to you the quotation to you .
Q5: You will test the machine before delivery ?
A5:Every machine we will test run before shipment.
Q6:How about the machine package ?
A6:We will delivery it by wooden case , full container machine will fix by steel wire.
