SVC/TND 0.5KVA Single Phase Automatic AC Voltage Regulator
- Category: >>>
- Supplier: Yueqing Junxiong Imp. & Exp. Co. Ltd.
Share on (1600229798024):
Product Overview
Description
Input voltage | Single-phase:140V-250V Three-phase:Phase voltage160V-250V Wire voltage:277V-430V | |||||||
Output voltage | Single-phase:0.5KVA-3KVA 220V and 110V 5KVA-60KVA 220V Three-phase:Phase voltage 220V Wire voltage:380V | |||||||
Waveform distortion | No additional waveform distortion | |||||||
Frequency | 50Hz/60Hz | |||||||
Ambient temperature | ＜75℉ | |||||||
Adjustable time | <1s( when input voltage has a change of 10%) | |||||||
Efficiency | ≥95% | |||||||
Dielectric strength | 1500V/1min | |||||||
Model(KVA) | Product size L*W*H(cm) | Packing size L*W*H(cm) | Net weight(kg) | Qty/CNY | ||||
SVC/TNS-1.5 | 40*36*17 | 52*48*28 | 7.0 | 1 | ||||
SVC/TNS-3 | 42*38*17 | 54*50*31 | 10.0 | 1 | ||||
SVC/TNS-4.5 | 42*38*19 | 54*50*31 | 15.0 | 1 | ||||
SVC/TNS-6 | 37*28*69 | 48*40*78 | 39.0 | 1 | ||||
SVC/TNS-9 | 35*33*78 | 48*45*90 | 48.0 | 1 | ||||
SVC/TNS-15 | 43*38*73 | 55*51*90 | 85.0 | 1 | ||||
SVC/TNS-20 | 43*51*91 | 64*55*106 | 124.0 | 1 | ||||
SVC/TNS-30 | 43*51*91 | 64*55*106 | 131.0 | 1 | ||||
SVC/TNS-45 | 65*43*95 | 78*55*110 | 197.0 | 1 | ||||
SVC/TNS-80 | 77*55*100 | 90*67*115 | 290.0 | 1 | ||||
SVC/TNS-100 | 77*55*100 | 90*67*115 | 350.0 | 1 | ||||
1.How can we get quotations?
A:We will send quotations within 24 hours after we get your enquiry. Urgent need you can call us or send us messages via Skype/Whatsapp.
2.Can we get sample to check your quality?
A:All items sample are available.Special make products will take a few days.
3.Can you do the design for packing?
A:Yes. We have ad team can assist you design inner and outer box if need. Can also help you design catalog if required.
4.How long to ship the sample?
A:Samples will be shipped by TNT DHL UPS EMS to arrive you around 7 days.
5.What is your terms of delivery?
A:Normally we work on EXW FOB CIF.
A:We will send quotations within 24 hours after we get your enquiry. Urgent need you can call us or send us messages via Skype/Whatsapp.
2.Can we get sample to check your quality?
A:All items sample are available.Special make products will take a few days.
3.Can you do the design for packing?
A:Yes. We have ad team can assist you design inner and outer box if need. Can also help you design catalog if required.
4.How long to ship the sample?
A:Samples will be shipped by TNT DHL UPS EMS to arrive you around 7 days.
5.What is your terms of delivery?
A:Normally we work on EXW FOB CIF.
