UV 9000 dual beam uv visible spectrophotometer with LCD screen (1600231758349)

Share on:

Price:$3,250.00 - $3,650.00
Price in USD:Details


Product Overview


Products Description

Product Paramenters

Model: UV-9000 Series Double Beam UV/VIS Spectrophotometer

UV-9000 series are wide screen double beam spectrophotometer.They adopt double beam long light path design to ensure high stability and accuracy and they are the best choice of high quality spectrophotometers.


1. Dual Beam Light Path Design
UV-9000 series adopt double light path design, it greatly reduces circuit fluctuation and stray light and ensures high stability of the instrument.
2. Powerful Stand-alone Operation System
UV-9000 series are euqipped with stand-alone operation system. Functions like spectrum scanning, standard curve, kinetics, multi wavelength scanning, DNA/Protein test, etc. can be directly completed on device without connecting PC software.
3. Long Light Path Design
The unique 520mm long light path design is adopted to improve the wavelength resolution and make the bandwidth of UV-9000S can be switched to 0.5nm.
4. UV Analyst PC Software
PC software is provided to connect device with PC for easy data output and analysis, the functions include wavelength scanning,standard curve, kinetics, multi wavelength scanning, DNA/Ptotein test, etc.
5. 16mm Rigid Aluminim Optical Base
A rigid 16mm thick die-cast aluminim base is used ass the optical mount to ensure high stability and reliability.
6. One-button Automatic Calibration System
The baseline, wavelength, dark current can be calibrated automatically to keep device in good running conditions.
7. 6 inches Large LCD display
Equipped with a 6 inches large LCD display to show results and curves directly on the screen.
8. Easy Data Output and Printing
Equipped with USB port to connect with PC, easy to export and print data and analysis report.

Optical System
Double Beam (1200 Lines/mm Grating)
Wavelength Range
0.5, 1.0, 2.0, 4.0 nm
Wavelength Accuracy
±0.1nm (D2 656.1nm), ±0.3nm @all
Wavelength Repeatability
Photometric Accuracy
Photometric Repeatability
Photometric Range
-0.3-3A, 0-200%T, 0-9999C
≤0.0005A/h@250nm, 500nm
Baseline Flatness
± 0.001A/h
Stray Light
≤0.03%T @ 220nm, 360nm
USB port & Parallel Port
320*240 Dots LCD
Tungsten Lamp & Deuterium Lamp
Silicon Photodiode
Power Requirements
AC 220V/50Hz or AC 110V/60Hz

Recommend Products

Our Advantages

Company Profile


Product packaging


Who are we?
Shanghai Metash Instruments is a professional manufacturer of science laboratory instruments, with over 12 years manufacturing and exporting experience.

What product do we have?
We manufacture full range of Spectrophotometers, TOC analyzer and Microwave digestion system and related accessories.

What certificate do we have?
All our products are CE, ISO, RoHS certified and have been exported to over 90 countries, over 80,000 Metash devices are serving for environmental, food, cosmetics, pharmaceutical, life science and chemical fields, etc.

What is the MOQ?
The MOQ is 1unit.

Do we accept OEM order?
Yes. We welcome OEM cooperation and will try our best to meet your special OEM requests.
